|Type:||96v 100ah Lithium Iron Phosphate Battery Pack||Size:||Customized Available|
|Case:||Metal Iron Box IP65||Rated Capacity:||100Ah|
|Rated Voltage:||102.4V||Cell Combine:||32S1P|
ev lithium ion battery pack,
electric car battery charger
32S LiFePO4 96v 100ah Lithium Iron Phosphate Battery Pack for EV
Battery can be customized as your requirement
We focus on 3.2V-360W LiFePO4 battery pack .
Battery solutions will be provided to you if you contact us .
Battery BMS parameters:
Protection circuitry for Li-Ion will support currents up to
100A continues with:
Over current protection. (OCP)
Short circuit protection. (SCP)
Over voltage protection. (OVP)
Under voltage protection. (UVP)
Over temperature protection. (OTP)
Cells active balancing, With fault limitation.
BMS will support RS-485 & SMBUS & CANBUS & I2C communication, to enable monitoring of battery status:
Pack Voltage and Current (including current direction)
Pack actual capacity / fuel gauge (SOC%)
Pack health – related to max capacity of the pack when
Pack Error Status, for all protection parameters;
balancing status, OCP, SCP, OVP, OTP, UVP
Total 8 12V 100Ah in series to 96V 100Ah .
Each module:4S30P to 12V 100Ah
Lithium for Industrial Vehicles and Heavy Duty applications
electric industrial vehicle
Industrial vehicles require very high energy capacity to be operational at any time and over a long operating period.
HKANON has robust products that meet the industry’s high standards.
The modular batteries designed by our teams are able to equip a few kilowatt hours for small industrial equipment, up to several Mega-Watt hours for heavy industry.
Application Examples :
|Standalone device 12V 330Ah 4.2kwh||1S3P||/||12.8kgs|
|Industry vehicle 48V 220Ah traction pack (11.2KWh)||4S2P||/||125.6kgs|
|Mini-van 96V 330Ah traction pack (34KWh)||8S3P||/||376.8kgs|
|Off-grid 48V1100Ah solar battery(50kwh)||4S10P||/||628kgs|
Each 12V Lithium-ion module has a built-in BMS that monitors operating conditions (temperature, over voltage, under voltage, etc..). An external BMS ensures optimal operation by a real-time monitoring of each module.
HKANON batteries embeds Lithium Iron Phosphate cylindrical cells (LiFePO4) that offers a high level of safety and long lifespan. HKANON solutions advantageously replace Lead acid solutions for many applications (Electric vehicles, off-grid or micro-grid systems, energy storage, etc.).
Work & storage conditions
Charge temperature: 0 °C to 50 °C
Discharge temperature: -20 - 75℃
Storage Temp: -30 - 45℃ (3 months), -30 - 25℃ (1 Year)
Humidity Conditions: RH < 90%
|Specifications||LiFePO4 96V 100Ah Battery Pack|
|Nominal capacity(C/5, 23°C)||100Ah|
|Storage||100kwh Lithium Ion Battery|
4S30P to 12.8V 100Ah each module,
8PCS 12.8V100Ah in series to 96V 100Ah
|Rated Discharge Current||100A|
|Peak Discharge Current||150A|
|Chareg Cut-off Voltage||134V|
|Discharge Cut-off Voltage||86.4V|
|Max Continuous Charge Current||0.2C-20A|
|Peak Charge Current||0.4C-40A|
|Charge Temperature Range||0-45C|
|Discharge Temperature Range||-20-60C|
|Pack size||260L*158W*246H or 270H*156W*348Lmm choices|
|Charging cycles||2000 cycles DOD>80%|
|Application||Lithium for Industrial Vehicles and Heavy Duty applications
electric industrial vehicle
|Case||IP65 Plastic Box|
