51.2V 608Ah LiFePO4 Forklift Battery with 4G Monitoring and SOC Display

Contact Now

51.2V 608Ah LiFePO4 Forklift Battery with 4G Monitoring and SOC Display

Minimum Order Quantity :	2 Packs	Price :	Negotiable
Packaging Details :	Sea Freight, Rail Freight or Approved Dangerous Goods Transportation	Delivery Time :	25–35 Working Days
Supply Ability :	200 Packs per Month

Place of Origin:	China	Brand Name:	Chalongfly
Certification:	UN38.3, MSDS	Model Number:	CLF-FM-51V608Ah-4G

Detail Information
System Voltage:	48V	Nominal Voltage:	51.2V
Rated Capacity:	608Ah	Nominal Energy:	31129.6Wh
Battery Chemistry:	LiFePO4	Battery Management System:	Built-in Smart BMS
Communication:	CAN, RS485 And 4G Optional	Battery Monitoring:	SOC Display And Remote Monitoring
Cycle Life:	More Than 4,000 Cycles	Customization:	Dimensions, Weight, Connector, Protocol, Current And Charger

Product Description

51.2V 608Ah Forklift Battery with 4G Monitoring

High-capacity LiFePO4 traction battery with 4G remote monitoring, SOC display and smart BMS for electric forklift fleets and demanding material handling operations.

Product Overview

The Chalongfly 51.2V 608Ah LiFePO4 forklift battery is developed for electric forklifts operating in warehouses, logistics centers, manufacturing facilities and other demanding material handling environments.

With 31129.6Wh of nominal energy, this battery is suitable for applications requiring extended operating time, multi-shift operation and reliable traction power.

The integrated smart BMS, SOC display and optional 4G communication provide local and remote access to important battery information. Battery dimensions, service weight, connector, communication protocol and charger can be customized according to the forklift model.

Core Battery Specifications

Product Model	CLF-FM-51V608Ah-4G
System Voltage	48V
Nominal Voltage	51.2V
Rated Capacity	608Ah
Nominal Energy	31129.6Wh
Battery Chemistry	LiFePO4 / Lithium Iron Phosphate
Battery Management System	Built-in Smart BMS
Battery Monitoring	SOC Display and Optional 4G Remote Monitoring
Communication	CAN, RS485 and 4G Optional
Cycle Life	More Than 4,000 Cycles
Enclosure and Weight	Customized According to Forklift Model
Charger	Matched Lithium Battery Charger Available

4G Remote Battery Monitoring

Optional 4G connectivity allows battery operating information to be transmitted to a compatible remote monitoring platform. This helps fleet operators check battery status and identify abnormal operating conditions without inspecting every forklift individually.

Remote State of Charge Monitoring	Battery Voltage Monitoring
Temperature Status Monitoring	Operating Alarm Information
Remote Fault Analysis	Fleet Battery Status Management

Monitoring functions depend on the selected BMS, 4G module, platform and project configuration.

Local SOC Display

The integrated SOC display allows operators and maintenance personnel to check important battery information directly at the forklift.

Battery state of charge
Battery voltage
Battery temperature
Charging and discharging status
BMS alarm and fault status
Communication and operating information when configured

Key Advantages for Forklift Fleets

31129.6Wh High-Capacity Energy

The 51.2V 608Ah configuration provides extended operating time for demanding warehouse and industrial material handling tasks.

Remote Fleet Visibility

Optional 4G monitoring helps operators review battery status across multiple forklifts and respond to alarms more efficiently.

Smart Battery Management

The integrated BMS monitors voltage, current, temperature and battery status and provides multiple electrical protection functions.

Opportunity Charging

The battery can be configured for charging during breaks and shift changes, helping reduce unnecessary equipment downtime.

Maintenance-Free LiFePO4 Technology

No watering, acid inspection or equalization charging is required, helping simplify daily battery maintenance.

Smart BMS Protection

Overcharge Protection	Over-discharge Protection
Over-current Protection	Short-circuit Protection
High-Temperature Protection	Low-Temperature Protection Optional
Cell Voltage Monitoring	Cell Balancing
SOC Monitoring	Fault and Alarm Recording

Typical Applications

Electric Counterbalance Forklifts Industrial lifting and material transportation	Reach Trucks Narrow-aisle warehouse lifting operations
Electric Stackers Pallet stacking and warehouse handling	Order Pickers Distribution center picking and transport
Multi-Shift Forklift Fleets Fleet applications requiring remote battery visibility	Manufacturing and Logistics Continuous industrial material handling operations

Lead-Acid Battery Replacement

The battery can be developed as a replacement for a compatible 48V lead-acid forklift battery. A complete compatibility evaluation is required before production.

Forklift brand, model and rated load
Original battery voltage and capacity
Battery compartment dimensions
Required battery service weight
Continuous and peak current requirements
Connector model, cable size and polarity
Vehicle controller and communication requirements
Original charger voltage and charging current

OEM and ODM Customization

Customized battery enclosure dimensions
Customized service weight and counterweight
Customized continuous and peak discharge current
Customized industrial connector and cable harness
Optional CAN and RS485 communication
Optional 4G remote monitoring
Customized SOC display and monitoring platform
Matched lithium battery charger
Optional low-temperature protection and heating
Customized logo, labels, color and export packaging

Information Required for Customization

Forklift Information	Brand, model, rated load and operating environment
Original Battery	Voltage, capacity, dimensions and service weight
Electrical Requirements	Continuous current, peak current, connector and cable
Daily Operation	Working hours, shifts, load and charging schedule
Monitoring Requirements	SOC display, CAN, RS485, 4G platform and remote functions

Quality Control

Cell capacity and internal resistance matching
Battery voltage and capacity verification
High-current charge and discharge testing
BMS protection function testing
SOC display and communication testing
4G monitoring function testing when configured
Connector, cable and insulation inspection
Final functional and packaging inspection

Packaging and Shipping

Each forklift battery is protected with moisture-resistant wrapping, reinforced cushioning and a heavy-duty export wooden case or pallet suitable for industrial battery transportation.

Shipping documents such as UN38.3 and MSDS can be prepared according to the final battery configuration and transportation route.

Frequently Asked Questions

How much nominal energy does the battery provide?

The 51.2V 608Ah configuration provides 31129.6Wh of nominal energy.

What information can be monitored remotely?

Depending on the selected configuration, the platform can display state of charge, voltage, temperature, operating status and alarm information.

Does the battery include an SOC display?

Yes. An SOC display can be integrated for local checking of battery level, voltage, temperature and alarm status.

Can this battery replace a lead-acid forklift battery?

Yes. Voltage, dimensions, service weight, discharge current, connector, controller and charger compatibility must be verified before replacement.

Can the dimensions and battery weight be customized?

Yes. The enclosure dimensions, installation structure and service weight can be customized according to the forklift battery compartment.

What information is required for customization?

Please provide the forklift model, original battery specifications, compartment dimensions, required weight, connector, working hours, charger and monitoring requirements.

Request a 4G-Monitored Forklift Battery Solution

Send Chalongfly your forklift model, original battery specifications, compartment dimensions, required service weight, connector, charger and remote monitoring requirements. Our team will evaluate the application and provide a suitable 51.2V LiFePO4 battery solution.
