Cabinet ESS 258KWH 289KWH 385KWH LiFePO4 Energy Storage Cabinet for Industrial and Commercial Energy Storage Cabinet
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
Minimum Order Quantity : | 10 units | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
Payment Terms : | T/T | Supply Ability : | 10000 units per month |
Place of Origin: | Hunan,China | Brand Name: | CLTF |
---|---|---|---|
Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLTF-0233 |
Detail Information |
|||
Rated Capacity:: | 100Ah | Nominal Voltage: | 51.2V |
---|---|---|---|
Energy: | 5120Wh | Weight: | 60KG |
Highlight: | Home Lithium Battery Pack 5kwh,Tesla Powerwall Solar Lithium Battery Pack,6000 Cycles Life Home Lithium Battery |
Product Description
6000 Cycles Life Tesla Powerwall Solar Home Battery 5kwh Power Wall Lithium Battery Pack
Specifications:
MODEL | CLTF-0233 |
ELECTRICAL SPECIFICATIONS | |
Cell Type - Chemistry | Prismatic- LiFePO4 |
Rated Capacity | 100Ah |
Rated Voltage | 51.2V |
Energy | 5120Wh |
Resistance | 30mΩ |
Self Discharge | <1.5% per month |
Maximum Modules in Parallel | 12 |
MECHANICAL SPECIFICATIONS | |
Dimensions (L x W x H) | 720*445*220mm |
Weight | 60Kg |
Enclosure Protection | IP65 |
DISCHARGE/CHARGE SPECIFICATIONS | |
Discharge Cut-off Voltage | 48V |
Max Continuous Discharging Current | 100A |
Peak Discharge Current | 150A for 3 seconds |
Recommended Discharge Current | 50A |
CHARGE SPECIFICATIONS | |
Charging Limited Voltage | 57.6V |
Max Charging Current | 50A |
Recommended Charge Current | 25A |
TEMPERATURE SPECIFICATIONS | |
Charge Temperature Range | 0~45℃ |
Discharge Temperature Range | -20~60℃ |
Recommended Operating Temperature | 15~35℃ |
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH |
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH |
Recommended Storage Temperature & Humidity Range |
15~35℃, 45~75%RH |
1. Most safe LFP battery technology, no cobalt.
2. Long lifetimes - >5000 cycles @85% DOD.
3. Easily expandable 5kWh Standard modules - up to 60kWh.
4. Standard module capacity can be customized.
5. Self-engineered BMS with cell level monitor.
6. Short circuit/ Over current/Over voltage/Over temperature protection.
7. Bluetooth APP available on request to see the status of the battery.
8. Strong steel case with white color(optional).
9. Canbus communication access.
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
