Cabinet ESS 258KWH 289KWH 385KWH LiFePO4 Energy Storage Cabinet for Industrial and Commercial Energy Storage Cabinet
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsAPP : +8618975107916
| Minimum Order Quantity : | 10 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLTF-0227 |
|
Detail Information |
|||
| Rated Capacity:: | 30Ah | Nominal Voltage: | 12.8V |
|---|---|---|---|
| Energy: | 384Wh | Size: | 165*175*125*125mm |
| Highlight: | 30Ah Lithium Solar Battery Storage System,LiFePO4 384Wh Solar Battery Storage System,12V 30Ah Lithium Solar Battery |
||
Product Description
Specifications:
| Nominal Voltage | 12.8V |
| Nominal Capacity | 30Ah |
| Energy | 384Wh |
| Internal Resistance | 70≤mΩ |
| Cycle Life | >2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity |
| Months Self Discharge | ≤3.5% per month at 25℃ |
| Charge Voltage | 14.6±0.2V |
| Charge Mode(CC/CV) |
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A. |
| Charger Current | 6A |
| Max.Charge Current | 15A |
| Discharge Current | 6A |
| Max. Continuous Current | 30A |
| Max.Pulse Current | 60A(<3S) |
| Disxcharge Cut-off Voltage | 10.0V |
| Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Disxcharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
| Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Water Dust Resistance | IP55 |
| Cell & Method | IFR32700 N60,4S5P |
| Plastic Case | ABS |
| Dimension(L*W*H*TH) | 165*175*125*125mm |
| Weight | 3.9kg |
| Terminal |
M5 |
Features:
1. Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions.
Design picture:
Applications:
