5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter

Minimum Order Quantity : 1 unit Price : Negotiable
Packaging Details : Wooden case and Carton case Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 1000 units per month
Place of Origin: Hunan,China Brand Name: CLTF
Certification: CE Model Number: CLF-0046

Detail Information

Product Name: All-in-one Energy Storage System Model No.: ONE BOX 5 Series
Battery Material: LiFePO4 LFP Dimensions(L×W×H): 580*1800*350mm
Application: House, Villa, Home Buildings Shipping Way: By Express, By Air, By Sea, Depends On Your Choices
Norminal Capacity: Up To 14.4kWh Norminal Output Power: Up To 5kW
Weight: 86kg+n*battery Module Standard Charge Current: 25A
Maximum Charge Current: 50A Standard Discharge: 25A
Maximum Discharge Rate: 50A
Highlight:

5KWH All In One Energy Storage System

,

10KWH All In One Energy Storage System

Product Description

5KWH & 10KWH & 15KWH With Hybrid Inverter All In One System Solar Energy Storage System For Home Storage

Datasheet

Energy Storage All In One
Model NO. R3KL1-A R3K6L1-A R4KL1-A R4K6L1-A R5KL1-A R6KL1-A
Inverter Parameters
Max. Input Power 4.6kW 4.6kW 6.0kW 5.0kW 7.0kW 7.0kW
Max. Input Current 2*14A 2*14A 2*14A 2*14A 2*14A 2*14A
Max. PV Voltage 550V 550V 550V 550V 550V 550V
MPPT Tracker/Strings 2 2 2 2 2 2
MPPT Range 125~550V 125~550V 125~550V 125~550V 125~550V 125~550V
Charge/Discharge Power

3.0kW



3.6kW 4.0kW 4.6kW 5.0kW 5.6kW
Phase

Single



Single Single Single Single Single
Rated Output Voltage 230V 230V 230V 230V 230V 230V
Rated Output Current 13A 16A 17.4A 20A 21.7A 26A
Grid Voltage Range 180~270V 180~270V 180~270V 180~270V 180~270V 180~270V
Rated Output Frequency 50 /60Hz 50 /60Hz 50 /60Hz 50 /60Hz 50 /60Hz 50 /60Hz
Backup Power Supply EPS EPS EPS EPS EPS EPS
Display LED LED LED LED LED LED
Operating Tempreture -10~60℃ -10~60℃ -10~60℃ -10~60℃ -10~60℃ -10~60℃
Relative Humidity 15~85% 15~85% 15~85% 15~85% 15~85% 15~85%



5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 0

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 1

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 2

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 3

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 4

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 5



Quality Control:

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 6

Product Quality

1) The cell is fixed with screws and fireproof tape to make the battery cell more stable

2) Two layers of fireproof sponges prevent collisions during transportation.

3)  All wires are well protected to prevent any risk of short circut

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 7
5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 8
5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 9





Product Packaging
To Pack Wall-Mounted Lithium Ion Battery well. Generally, as follow:

1) Inner box - Carton - Pallet- Container

2) Packaging also can be made by customers requirements

5KWH 10KWH 15KWH All In One Energy Storage System With Hybrid Inverter 10



FAQs:


Q: Are you manufacturer?

A: We are manufacturer, and we sincerely welcome you to visit our factory!


Q. Can I print my LOGO on it?

A: YES, LOGO/sticker/OEM/ODM welcomed


Q: Do you accept OEM/ODM?

A: Yes,it is available.We have OEM group to design battery case.

Thanks to send us your requirements to custom the batteries.


Q: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.


Contact us for more informations!
