CLF OEM LiFePO4 EV Lithium Battery Pack 96V 120V 360V 100ah 200Ah High Voltage Battery Pack For Low Speed Vehicle Truck
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsAPP : +8618975107916
| Minimum Order Quantity : | 1-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | CE/ROHS/MSDS/UN38.3 | Model Number: | CLFC-0102 |
|
Detail Information |
|||
| Features: | Cost Effective, Fast Delivery, Stable Structure | Battery Type: | Lifepo4 Battery，li-ion Battery，lithium Battery，NMC |
|---|---|---|---|
| Voltage: | 307.2v | Capacity: | 50ah,60ah,100ah,200ah |
| Application: | Electric Vehicle，electric Boat，electric Yacht,marine | Dimension: | Customized |
| OEM/ODM: | Yes | Keywords: | Lithium Battery,lifepo4 Battery Pack,nmc Battery,marine Battery |
| Cycle Life: | 3000 Times | Battery Case: | Metal |
| Transport Package: | Foam & Plywood Case | Waterproof Standard: | IP67 |
| Weight: | 300kg | ||
| Highlight: | 100AH Rechargeable Lifepo4 Battery Pack,200AH Lithium Ion Battery,Marine Boat Lifepo4 Battery Pack |
||
Product Description
Product Paramter
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 80Ah |
| Rated Voltage | 320V |
| Energy | 25.6kWh |
| Resistance | 30mΩ |
| Self Discharge | <4% per month |
| Modules in Series | 320V 80Ah battery pack |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 500*370*160mm |
| Weight | 190Kg |
| Enclosure Protection | IP67 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 280V |
| Max Continuous Discharging Current | 160A |
| Peak Discharge Current | 400A for 30 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 365V |
| Max Charging Current | 40A |
| Recommended Charge Current | 20A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45ºC |
| Discharge Temperature Range | -20~60ºC |
| Recommended Operating Temperature | 15~35ºC |
| Storage Temperature & Humidity Range (Less than 1 month) |
-20~35ºC, 45~75%RH |
| Storage Temperature & Humidity Range (Less than 3 months) |
-10~35ºC, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35ºC, 45~75%RH |
| OEM | |
| Available on request | yes |
Features of Battery:
Lighter weight, smaller size.
High-temperature performance.
Extremely safe, no explosion, no fire under collision.
Strong over-discharge resistance and charge retention.
Strong charging acceptance and quick-charging capability.
Excellent large current discharge performance especially in startup and climbing.
Large capability and long life for all high-power output applications.
Environmentally friendly non-toxic, non-contaminating, no rare metal.
Low self-discharge and good discharge performance at low temperatures.
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
