CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike

Minimum Order Quantity : 1 unit Price : Negotiable
Packaging Details : Wooden case and Carton case Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 10000 Piece/Pieces per Month
Place of Origin: Hunan,China Brand Name: Chalong Fly
Certification: CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc Model Number: CLF-R015

Detail Information

Product Name: Public Charging Cabinet Battery Swap Station Battery Swapping Cabinet Type: Electric, Fast Charger
Usage: Motorcycle / Scooter Function: QC4.0, VOOC 4.0, SuperVOOC 1.0, SuperVOOC 2.0
Port: 6 X USB, DC, AC Input Voltage And Current:: 100-240V/0.15A, 100-240V/0.6A, 100-240V/0.5A
Output Voltage And Current: 12V/1.25A Output Power: 100W
Application: Multi Device Charging Station Use For: Motorcycle/Scooter
Feature: Safe Conveient Cycle Life: 2000
Advantage: Multi-Protection Safety Protection Keywords: Battery Swapping Cabinet
OEM/ODM: Yes
Highlight:

CLTF Solar Battery Swap Module

,

Ebike Battery Swap Module

,

ODM Battery Swapping Charging Station

Product Description

CLF Public Charging Cabinet Battery Swap Station Module Ev Scooter Motorcycle Ebike Solar Battery Swapping Charging Station

If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.



Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 0

Product Description
Battery Swap Stations Cabinet Charging Station Cabinet Battery Swap System For Motorcycle
Item Spec
Construction material Carbon steel plate
Material thickness 1.2mm
Appearance process Painting silk printing
Optimum structure Power push and pull battery
Single Slot bearing 30Kg
Slot number 12
Move Anti-skid roller,Bearing capacity of 800kg
Single Slot empty size 260*230*400mm,Customizable
Cabinet size 1100*600*1650mm
Weight 175Kg
This unit is the lithium battery charging cabinet, basic characteristics are as below:
Input voltage Output voltage Input current Rated input power Rated output power
220VAC/ 176-
264VAC
4890VDC ≤56A 10000W 750W

Environmental characteristics

Item Spec Remark
Operating ambient temperature 0℃ ~ 40℃ 24H at full load, normal performance
Storage ambient temperature -20℃ ~ 60℃ 48H, normal temperature recovery
2H, normal work
Operating ambient humidity 10% ~ 90% No condensation
Storage ambient humidity 10% ~ 90% No condensation
Above sea level 2000m No rated power reduction is achieved
below 2000m
Cooling mode Air blast cooling AC fan
IP Grade IP54 Suitable for outdoor use

Input characteristics

Item Spec Remark
Input voltage range 176-264VAC Rated voltage220VAC
Input voltage frequency range 47-63HZ Rated frequency is 50/60Hz
Total air switch 80A 1P+N Rated voltage220VAC
Input current (full load) ≤56A Rated voltage220VAC

Communication mode

Item Spec Remark
4G Yes/Selectable 4g Network Communication Control
WIFI Yes/Selectable The wifi network communication control
RJ45 No/Selectable RJ45 interface communication
Display screen 7 Inch The real-time screen displays the charging information
Sound Yes Suona

Output characteristics

Item Spec Remark
Output voltage 48~90VDC Output intelligent control
Output current ≤15A A battery Slot can output a 15A current
LED indication Green light Standby mode
  Red light Charge mode
  Red light to green light Charging end
Charging method Plug way
Start time ≤3S Charger power supply and slow start, reduce the impact current

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 1

Technical Services

1, smoke sensor: when the fire just happened, smoke into the detector will trigger the alarm.

2, aerosol device: through the isolation of oxygen, heat absorption, cooling, interrupt the combustion of free radicals, fully submerged covering space, to achieve efficient fire extinguishing purpose

3, temperature sensor: when the temperature rises suddenly, the detector will send an alarm signal to the server to remind the management

4, intelligent electronic lock: scan code automatically unlock, add solid core, with electronic control lock 100,000 + times of use, durable

5, water immersion device: water immersion power, lightning leakage prevention, safety protection

6. FCL fan: FCL fan for temperature control and heat dissipation. When it reaches 40 degrees, open the fan heat dissipation; Turn off the fan when the temperature is lower than 40 ° C, saving energy

7, anti-theft ability: anti-theft door lock, built-in door, no exposed screws

8. Lightning protection ability: lightning protection and leakage prevention

9, waterproof level: IP56, the cabinet body waterproof structure, PCB board in the cabinet are coated with three anti-paint

10, windproof level: resistance to 60m/s wind

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 2







CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 3CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 4

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 5

Application

It is used for takeout riders, logistics distribution, shared electric vehicles, batteries of the same specification, industrial parks, commercial centers, road parking points, etc

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 6

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 7

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 8

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 9

CLF Public Charging Cabinet Solar Battery Swapping Station Module Ev Scooter Motorcycle Ebike 10



FAQs:


Q: Are you manufacturer?

A: We are manufacturer, and we sincerely welcome you to visit our factory!


Q. Can I print my LOGO on it?

A: YES, LOGO/sticker/OEM/ODM welcomed


Q: Do you accept OEM/ODM?

A: Yes,it is available.We have OEM group to design battery case.

Thanks to send us your requirements to custom the batteries.


Q: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.


Contact us for more informations!
