32700 LiFePO4 Battery Cell 3.2V 6000mAh Lithium Iron Battery Cell For Electric Motorcycle Escooter Cars Ebike
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 10-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | MSDS, UN38.3,CE, ROHS | Model Number: | CLFC-0086 |
|
Detail Information |
|||
| Battery Type: | 3.2V Prismatic LiFePO4 Battery | Capacity: | 50Ah 80Ah 100Ah 200Ah 230Ah 250Ah 300Ah |
|---|---|---|---|
| Nominal Voltage: | 3.2 Volt | Discharge Current: | 1C~3C |
| Weight: | 1.2KG~5.4KG | Cycle Life: | 3500 Times |
| Usage: | Storage | The Discharge Rate: | 2.56V |
| Storage Type: | Solar System | ||
| High Light: | 105ah 3.2 v lifepo4 battery,prismatic 3.2 v lifepo4 battery,lifepo4 battery 12v 50ah |
||
Product Description
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
|
Items
|
Specifications
|
|
Nominal Voltage
|
3.2V
|
|
Nominal Capacity
|
280Ah
|
|
Standard Charge Current
|
0.2C-0.5C
|
|
Max. Charge Current
|
1C
|
|
Continuous Discharge Current
|
1C
|
|
Peak Discharge Current
|
2C
|
|
Charge Cut-off Voltage
|
3.9V
|
|
Discharge Cut-off Voltage
|
2V
|
|
Inner Resistance
|
≤ 0.3mΩ (At 0.2C rate, 2.0V cut-off)
|
|
Weight
|
5.5kg
|
|
Dimension
|
Length: 205mm
Width: 175mm Thickness: 72mm |
|
Operating Temperature
|
Charging: 0°C ~ 45°C
Discharging: -20°C ~ 55°C |
|
Storage Temperature
|
optimal store temperature of 23 ± 5°C for long term storage
|
|
Life Cycle
|
≥3500 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard)
|
Features:
1. High capacity and stable discharge voltage
2. Longer working time with high performance
3. Lightweight with a small size
4. Outstanding discharge properties and small internal resistance
5. No memory effect, good discharge ability, and high load, and resist high temperature
6. Pollution free for environmental protection
7. 100% Authentic original li-ion rechargeable battery
8. Build in anti-explosion protection and circuit protection
