Lithium Battery 3.1V 50mah Sodium-ion Lithium Battery Lithium Rechargeable For 100KWH 150KWH Energy Storage System
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
Minimum Order Quantity : | 10-1000 units | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
Payment Terms : | T/T | Supply Ability : | 1000 units per month |
Place of Origin: | Hunan,China | Brand Name: | CLTF |
---|---|---|---|
Certification: | CE/ROHS/UL/UN38.3/CB/MSDS | Model Number: | CLFC-124 |
Detail Information |
|||
Battery Type: | Lithium/LiFePo4 / NMC Battery | Model Number: | 3.2V Prismatic LiFePO4 Battery |
---|---|---|---|
Application: | BOATS, Golf Carts, Electric Power Systems, Solar Energy Storage | The Charging Ratio: | 1C-3C |
Capacity: | 50Ah 80Ah 100Ah 105Ah 202Ah 230Ah 280Ah 300Ah | Discharge Current: | 1C~3C |
OEM/ODM: | Available | Nominal Voltage: | 3.2 Volt |
Cycle Life: | ≥3500 Times |
Product Description
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
Items
|
Specifications
|
Nominal Voltage
|
3.2V
|
Nominal Capacity
|
280Ah
|
Standard Charge Current
|
0.2C-0.5C
|
Max. Charge Current
|
1C
|
Continuous Discharge Current
|
1C
|
Peak Discharge Current
|
2C
|
Charge Cut-off Voltage
|
3.9V
|
Discharge Cut-off Voltage
|
2V
|
Inner Resistance
|
≤ 0.3mΩ (At 0.2C rate, 2.0V cut-off)
|
Weight
|
5.5kg
|
Dimension
|
Length: 205mm
Width: 175mm Thickness: 72mm |
Operating Temperature
|
Charging: 0°C ~ 45°C
Discharging: -20°C ~ 55°C |
Storage Temperature
|
optimal store temperature of 23 ± 5°C for long term storage
|
Life Cycle
|
≥3500 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard)
|
Features:
1. High Capacity and Stable Discharge Voltage.
2. Light weight, small size, and high performance.
3. Small internal resistance.
4. Outstanding Discharge properties and Storage Capacity.
5. Pollution-free, long cycle life.
6.No memory effect.
7. Existing stock for short delivery time.
8. OEM orders are available.
