CLF Lithium Iron Phosphate Rechargeable LiFePO4 Battery Pack 100Ah 200Ah 300Ah 400Ah 12V 24V For RV Camper Boat
Contact Person : CLF
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 1-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLTF-0232 |
|
Detail Information |
|||
| Rated Capacity:: | 100Ah/200Ah/300Ah | Nominal Voltage: | 51.2V |
|---|---|---|---|
| Energy: | 5120Wh | Weight: | 60KG |
| Battery Type: | Li-ion (LiFePO4) | AC Input Frequency: | 50 / 60Hz |
| OEM/ODM: | Available | Capacity: | 2.56kWh*N(N=3-8) Or 5.12Kwh*N(N=3~6) |
| High Light: | LiFePO4 48V 100Ah Solar Panel Battery,Tesla Powerwall Solar Panel Battery 5kWh,Off Grid Solar Panel Battery Pack |
||
Product Description
If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.
Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| MODEL | CLTF-0232 |
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 100Ah |
| Rated Voltage | 51.2V |
| Energy | 5120Wh |
| Resistance | 30mΩ |
| Self Discharge | <1.5% per month |
| Maximum Modules in Parallel | 12 |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 720*445*220mm |
| Weight | 60Kg |
| Enclosure Protection | IP65 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 48V |
| Max Continuous Discharging Current | 100A |
| Peak Discharge Current | 150A for 3 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 57.6V |
| Max Charging Current | 50A |
| Recommended Charge Current | 25A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
|
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH |
|
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35℃, 45~75%RH |
Features:
1. Most safe LFP battery technology, no cobalt.
2. Long lifetimes - >5000 cycles @85% DOD.
3. Easily expandable 5kWh Standard modules - up to 60kWh.
4. Standard module capacity can be customized.
5. Self-engineered BMS with cell level monitor.
6. Short circuit/ Over current/Over voltage/Over temperature protection.
7. Bluetooth APP available on request to see the status of the battery.
8. Strong steel case with white color(optional).
9. Canbus communication access.
10. IP65 waterproof.
11. OEM logo available.
To Pack Wall-Mounted Lithium Ion Battery well. Generally, as follow:
