48V 10kWh 20kWh LiFePO4 All-in-One Solar Energy Storage System Residential Energy Storage System

Contact Now

48V 10kWh 20kWh LiFePO4 All-in-One Solar Energy Storage System Residential Energy Storage System

Minimum Order Quantity :	2 Packs	Price :	Negotiable
Packaging Details :	Each battery is packed in a protective PE bag with foam cushioning and a strong export carton. Wooden cases or pallets are available for bulk orders.	Delivery Time :	25–35 Working Days
Supply Ability :	300 Packs per Month

Place of Origin:	Hunan,China	Brand Name:	Chalongfly
Certification:	UN38.3, MSDS	Model Number:	CLF-AIO-48V-10-20K

Detail Information

Highlight:

48V All-in-One Solar Energy Storage System

LiFePO4 Residential Energy Storage System

10kWh 20kWh All-in-One Solar Energy Storage System

Product Description

Integrated Residential Solar Energy Storage

48V 10kWh 20kWh All-in-One LiFePO4 Solar Energy Storage System

Integrated solar battery and inverter solutions for home backup, photovoltaic self-consumption and off-grid power.

Complete Battery and Solar Inverter Integration

Chalongfly all-in-one solar energy storage solutions are designed for residential projects requiring integrated battery storage and power conversion.

The system combines LiFePO4 battery technology, smart battery management and compatible solar inverter configurations to help manage photovoltaic electricity, household loads and stored backup energy.

The 10kWh and 20kWh energy classes allow solar installers, distributors and homeowners to evaluate different storage capacities according to daily consumption and expected backup duration.

10kWh and 20kWh Energy Storage Options

Specification	10kWh Class	20kWh Class
Reference Nominal Voltage	51.2V	51.2V
Reference Capacity	200Ah	400Ah
Reference Nominal Energy	10.24kWh	20.48kWh
Battery Chemistry	LiFePO4	LiFePO4
Smart BMS	Available	Available
Solar Inverter	Configured by Project	Configured by Project

These are reference battery configurations for system selection. Final electrical specifications and component combinations are determined by the approved product model.

Integrated Solar Inverter and Charging

A compatible inverter converts stored battery energy into AC electricity for household loads and enables the selected solar power operating modes.

Integrated Power Conversion

Inverter output power, AC voltage, phase configuration and surge capability are selected according to the destination market and connected electrical loads.

Solar MPPT Charging

MPPT-equipped configurations can convert available photovoltaic energy into battery charging power while operating within the approved PV input limits.

Compatible AC Charging

A suitable inverter-charger can support AC charging and configurable operating priorities, depending on the final system architecture.

Intelligent LiFePO4 Battery Management

Smart battery management helps coordinate the charging, discharging and protection functions of the LiFePO4 energy storage system.

Battery voltage and current monitoring
Cell voltage monitoring and balancing
Overcharge and over-discharge protection
Over-current and short-circuit protection
Temperature monitoring and protection
Battery state-of-charge management
Communication with compatible inverter systems

Solar Self-Consumption and Residential Backup

Daytime Solar Energy Storage Store available photovoltaic electricity for later consumption when solar generation decreases.	Nighttime Household Power Use stored battery energy through a compatible inverter to support evening household loads.
Home Backup Power Supply selected household equipment during grid interruptions with an approved backup configuration.	Off-Grid Solar Homes Support compatible independent solar energy systems in houses, cabins and remote properties.

Battery Capacity and Inverter Power Selection

Battery energy capacity and inverter output power are separate design requirements.

The energy capacity determines how much nominal electricity can be stored, while the inverter power rating determines how much AC power can be supplied to connected loads at a given time.

Matching the Correct System

Please provide average household consumption, maximum continuous load, appliance starting surge, solar array specifications and required backup duration. The battery and inverter configuration can then be evaluated as one electrical system.

Communication and Monitoring

Battery and inverter communication enables supported equipment to exchange operating information, charging limits and system status.

CAN / RS485	According to Selected BMS and Inverter
Battery SOC	Available with Compatible Monitoring
Local Display	Configuration-Dependent
WiFi Monitoring	Optional
Inverter Compatibility	Verified According to Protocol and Model

OEM and ODM Energy Storage Solutions

Chalongfly supports customized battery and energy storage system configurations for solar equipment brands, distributors and installation projects.

10kWh and 20kWh-class battery configurations
LiFePO4 battery module and BMS selection
Solar inverter and MPPT configuration
AC voltage and frequency matching
Communication protocol configuration
Monitoring and display options
Enclosure and installation design
Power and communication interfaces
OEM model number, label and logo
Private-brand packaging and product documentation

Frequently Asked Questions

What battery energy options are available?

The featured system options cover 10kWh and 20kWh energy classes. Reference 51.2V configurations provide 10.24kWh at 200Ah and 20.48kWh at 400Ah.

Does this system include an inverter?

Integrated solar inverter configurations are available. The exact inverter power, functions and equipment included are specified in the approved quotation.

Can solar panels charge the battery?

Yes, with a suitable MPPT-equipped solar inverter configuration. PV input voltage, power and current must match the inverter specifications.

Can the system provide backup power?

Backup power is available with a compatible backup-capable inverter and correctly installed electrical transfer and protection equipment.

Is the battery suitable for off-grid operation?

The system can be configured for compatible off-grid solar applications according to the inverter, charging system and load requirements.

Can it export energy to the public grid?

Grid export requires a specifically approved grid-interactive inverter and compliance with the destination country's utility and electrical regulations.

Can monitoring functions be customized?

Battery monitoring, local display, wireless communication and BMS protocol options can be evaluated according to the selected hardware.

What information is required before ordering?

Please provide the destination country, required energy capacity, AC voltage and frequency, household power demand, solar PV details, backup time, installation conditions and estimated order quantity.

Configure Your 10kWh or 20kWh All-in-One Solar ESS

Contact Chalongfly with your required energy capacity, inverter output, solar array specifications, household loads and installation requirements. Our team will help evaluate the appropriate LiFePO4 battery, smart BMS, MPPT charging and integrated inverter configuration for your residential solar energy storage project.
