CLF OEM LiFePO4 EV Lithium Battery Pack 96V 120V 360V 100ah 200Ah High Voltage Battery Pack For Low Speed Vehicle Truck
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsAPP : +8618975107916
| Minimum Order Quantity : | 2 unit | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | Chalong Fly |
|---|---|---|---|
| Certification: | CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc | Model Number: | CLFLE218 |
|
Detail Information |
|||
| Battery Type:: | Lifepo4 Battery | Voltage:: | 48V |
|---|---|---|---|
| Capacity:: | 200AH | Size:: | Customized |
| OEM/ODM:: | Yes | Transport Package:: | Foam & Plywood Case |
| Waterproof Standard:: | IP67 | HS Code:: | 8507600090 |
| Features:: | Cost Effective, Fast Delivery, Stable Structure | Application:: | Electric Vehicle，electric Boat，electric Yacht,marine |
| Highlight: | 72V 170Ah Electric Motorcycle Battery,IP67 Waterproof LiFePO4 Battery Pack,4000 Cycles OEM Battery Pack |
||
Product Description
The ultimate power solution for electric motorcycles, trikes, and heavy-duty two-wheelers. With a massive 12.24 kWh energy capacity, this battery is engineered for riders who demand maximum range, consistent power delivery, and uncompromising reliability. Whether you're tackling long-distance touring, daily cargo delivery, or off-road adventures, this battery keeps you moving.| Specification | Details |
|---|---|
| Nominal Voltage | 72V |
| Nominal Capacity | 170Ah |
| Total Energy | 12.24 kWh |
| Cell Chemistry | Lithium Iron Phosphate (LiFePO₄) |
| Cell Configuration | 24S1P (24 cells in series) |
| Cell Origin | Automotive Grade A, sourced from Tier-1 suppliers (e.g., BYD, Gotion) |
| Cycle Life | ≥ 4000 cycles @ 80% DoD, 1C rate |
| Max Continuous Discharge | 200A |
| Peak Discharge (10 sec) | 400A |
| Recommended Charge Current | 30A (0.18C) |
| Max Charge Current | 85A (0.5C) |
| Charge Cut-off Voltage | 86.4V ± 0.5V |
| Discharge Cut-off Voltage | 60V ± 0.5V (under load) |
| BMS Type | Smart 250A BMS with CAN bus & Bluetooth |
| BMS Protection | Over-voltage, under-voltage, over-current, short circuit, temperature |
| Cell Balancing | Active balancing (optional) |
| Communication Protocol | CAN 2.0, RS485, UART |
| Dimensions (L × W × H) | 580 × 290 × 255 mm |
| Weight | Approx. 85 kg |
| Enclosure Material | Steel plate with electrostatic painting |
| Ingress Protection | IP65 (dust-tight, water-resistant) |
| Terminal Type | Dual Anderson SB175 connectors |
| Charge Temperature Range | 0°C to 50°C |
| Discharge Temperature Range | -20°C to 60°C |
| Storage Temperature | -10°C to 35°C (recommended) |
| Certifications | UN38.3, CE, FCC, RoHS |
Heavy electric motorcycles (e.g., Zero SR/F, LiveWire One – with custom battery tray)
Electric trikes and cargo bikes (for delivery fleets)
Custom-built high-performance scooters (with aftermarket controllers)
Electric off-road bikes and enduros
