CLF OEM LiFePO4 EV Lithium Battery Pack 96V 120V 360V 100ah 200Ah High Voltage Battery Pack For Low Speed Vehicle Truck
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsAPP : +8618975107916
| Minimum Order Quantity : | 1 | Packaging Details : | wooden case |
|---|---|---|---|
| Delivery Time : | 30-40days | Payment Terms : | L/C,T/T |
| Supply Ability : | 10/month |
| Place of Origin: | Changsha, Hunan, China | Brand Name: | CLF |
|---|---|---|---|
| Certification: | UN38.3/MSDS | Model Number: | CLF-R5115 |
|
Detail Information |
|||
| Brand: | CLF/ Customized | Battery Type: | LiFePO4 |
|---|---|---|---|
| Voltage: | 627V Or Customized | Capacity: | 456Ah Or Customized |
| Weight: | 5000KGS | Charging Current: | 1500A |
| Discharging Current: | 350A | Protection Grade: | IP67 |
| Communication: | CAN | ||
| Highlight: | 627V LiFePO4 Battery Pack,456Ah High Voltage Battery Pack,IP67 Protected Lithium Iron Phosphate Battery Pack |
||
Product Description
The lithium battery developed in conjunction with the main unit for the concentration of mine gas adopts solid electrolyte inside the battery, the latest lamination technology, supports fast charging and deep discharge efficiency, and is managed by a high-intelligence BMS for the battery cells, automatically initiating protection, which conforms to the value concept of safety and low noise.
| Item | Parameter |
|---|---|
| Battery Type | LiFePO4 |
| Capacity | 456AH |
| Voltage | 627V |
| Operating voltage | 549V-686V |
| Charging cutoff voltage | 549V |
| Discharging cutoff voltage | 686V |
| Max continuous charging current | 250A |
| Max continuous discharging current | 350A |
| Peak discharging current | 900A, 30s |
| Charging temperature | 0°C~55°C |
| Discharging temperature | 30°C~60°C |
| Dimension | 326*819*1321mm |
| Weight | 5000KG |
| Thermal management method | Liquid cooling(Heat dissipation +PTC heating) |
Lithium iron phosphate battery cells, combined with explosion-proof enclosures and multiple intelligent protections, are specially designed for harsh underground environments.
It features high energy density and supports high-power fast charging, significantly enhancing the single-shift operation efficiency of the equipment.
Modular anti-seismic structure and high-strength shell, fearless of severe vibration and impact underground.
It is equipped with a built-in BMS system to monitor the battery health status in real time, supports remote operation and maintenance, and is safe and controllable.
It operates within a wide temperature range, requires no daily maintenance, and significantly reduces the later usage and labor costs.
