CLF OEM ODM 3.2V 3.3Ah 6.4V 3.3Ah Lithium Battery LiFePO4 battery for Emergency lights

Product Description

Product Introduction:

When the main power supply is cut off, the CLF lithium iron phosphate battery can immediately switch to various emergency lighting backup power sources. CLF batteries have excellent anti-float charging performance and are suitable for long-term charging sites.

Application scenarios:

Emergency lights, etc

Product Features:

High capacity density and long battery life

The long float charging design enables the battery to remain in a float charging state for a long time

Long service life, high stability and low maintenance cost

Environmentally friendly design that complies with RoHS requirements

Low self-discharge rate

3.2V 3.3Ah 1S1P Emergency Light Battery - Product Description:

Nominal voltage: 3.2V

Nominal capacity: 3.3Ah

Power: 10.56Wh

Internal resistance: ≤105mΩ

Self-discharge: less than 1% per month

Dimensions (length x width x height): φ26.5*70mm

Weight: 0.1Kg

Output terminal: KR2001H-02P

Shell material: PVC

IP rating: IP42

Battery cell: 26650 - LiFePO4

Maximum continuous amplification current: 3A

BMS discharge protection current: 7A

Over-discharge protection voltage: 2V

Over-discharge recovery voltage: 2.5V

Short-circuit protection: Yes

Charging current: 1.6A

Maximum charging current: 3A

Charging voltage: 3.65V

Overcharge protection voltage: 3.9V

Overcharge recovery voltage: 3.75V
