Cabinet ESS 258KWH 289KWH 385KWH LiFePO4 Energy Storage Cabinet for Industrial and Commercial Energy Storage Cabinet
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 1 unit | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 1000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLF |
|---|---|---|---|
| Certification: | CE,MSDS | Model Number: | CLF-R0262 |
|
Detail Information |
|||
| Nominal Capacity: | 600Ah | Nominal Voltage: | 12.8V |
|---|---|---|---|
| Cycle Life: | 6000 Times | Size: | 480*340*235mm Customized |
| Weight: | 60kg | Charging Current: | 150A |
| Discharge Current: | 200A | BMS Function: | Overcharge, Overdischarge, Overcurrent, Short Circuit, Etc |
| Case Material: | Metal Case Or Stainless Steel Case(Customized) | Warranty: | 5Years |
| Optional: | Bluetooth | Application: | RV,air Conditioners,water Heaters,digital Equipment Etc |
| Highlight: | 12V 600Ah LiFePO4 Battery Pack,Lithium Iron Phosphate Battery For RV,Lithium Iron Phosphate Battery For Boat |
||
Product Description
CLF Lithium Iron Phosphate Rechargeable Battery LiFePO4 Battery Pack 100Ah 200Ah 300Ah 400Ah 12V 24V For RV Camper Boat
Specification for 12V 600AH
|
Battery model |
CLF12400 |
||
|
Voltage |
12.8V |
||
|
Battery Type |
LiFePO4 |
||
|
Connection |
4S2P |
||
|
Capacity |
600AH |
||
|
Charging voltage |
14.6V |
||
|
Discharge cutoff voltage |
10V |
||
|
Maximum charging current |
150A |
||
|
Maximum discharge current |
300A |
||
|
Charging temperature |
0～45℃ |
||
|
Discharge temperature |
-10～45℃ |
||
|
storage temperature |
-20～60℃ |
||
|
BMS protection strategy |
Eight major protections |
||
|
Weight(kg) |
60kg |
||
|
DimensionsL*W*H(mm) |
480*240*235mm |
||
|
Display method |
Battery display/external screen display |
||
|
Fire and explosion proof |
Built-in fire extinguishing device |
||
|
heating |
|
||
|
cooling method |
natural cooling |
||
|
battery casing |
metal shell |
||
|
communication method |
RS485/CAN/GSM(option) |
||
Advantages of LifePO4 compared with lead-acid batteries:
-Various kinds of green, non-toxic and non-polluting raw materials.
-Long lifespan (2000-8500 cycles, lead-acid is ~400).
-Lightweight-save 60% weight
-Charging speed increased by 6 times
-Reduce the total life cycle cost.
-No heavy metals or acids; environmentally friendly
-Maintenance-free.
-Internal BMS; higher reliability.
-No memory effect.
-Less affected by high temperature.
-Can be installed in any direction
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Contact us for more informations!
