CLF OEM ODM Golf Cart Forklift Motorcycle Lifepo4 Lithium Battery 36V 48V 72V BMS CAN RS485 6000cycles Lead Acid
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 10-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 1000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | CE/ROHS/UL/UN38.3/CB/MSDS | Model Number: | CLFC-229 |
|
Detail Information |
|||
| Voltage: | 24V/36V/48V/60V/72V/96V | Battery Type: | LiFePO4 Lithium Battery |
|---|---|---|---|
| Capacity: | 20AH-200AH | Application: | Toys, Power Tools, Home Appliances, Golf Carts, BOATS, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, Electric Vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies |
| Certification: | CE/ROHS/MSDS/UN38.3 | OEM/ODM: | Available |
| Usage: | UPS System Battery | ||
| High Light: | 100AH Lithium Ion Battery,60V Wheelchair Lithium Ion Battery |
||
Product Description
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
|
Function Parameter
|
|||
|
Norminal Battery Energy
|
3900wh
|
||
|
Norminal Capacity
|
65Ah
|
||
|
Norminal Voltage
|
60V
|
||
|
Internal Resistance
|
≤22mΩ
|
||
|
Cycle Life
|
>6000
|
||
|
Months Self Discharge
|
<3%
|
||
|
Charge Data
|
|||
|
DC Normal Charge Voltage
|
54.75±1Vdc
|
||
|
Charge Mode
|
0.2C to 54.75V, then 54.75V,charge current to 0.02C (CC/CV)
|
||
|
Recommended Charger Current
|
≤50A
|
||
|
Allowed Max. Charge Current
|
50Adc
|
||
|
Charge Cut-off Voltage
|
54.75±1Vdc
|
||
|
Discharge Data
|
|||
|
Continuous Discharge Current
|
50A
|
||
|
Allowed Max. discharge current
|
100A (option:100Adc)
|
||
|
Rang of DC discharge voltage
|
37.5V-54.75Vdc
|
||
|
Working Condition
|
|||
|
Charge Temperature
|
0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity
|
||
|
Discharge Temperature
|
-20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity
|
||
|
Storage Temperature
|
0℃ to 40℃ (32℉ to 104℉) @60±25% Relative Humidity
|
||
|
Enclosure Protection Level
|
IP20
|
||
|
Mechanical Data
|
|||
|
Cell & Method
|
48V100Ah, Prismatic
|
||
|
Shell material
|
Iron
|
||
Features:
