Lithium 18650 Battery Pack 12V 100ah 400ah 200ah 300ah 12.8 V Lifepo4 Battery

Product Description

Solar Lithium Battery 12v 400ah 200ah 300ah 100ah 18650 Battery Pack Cell Box 12.8v Lifepo4 Battery

Nominal Voltage	12.8V (Optional: 12V/24V/48V/72V TO 1000V)
Nominal Capacity	400AH (Optional: 5AH TO 2000AH)
Energy	5120Wh
Max Discharge Current	200A / Customization
Max Charge Current	100A
Discharge Temperature	-20 to +60°C @60±25% Relative Humidity
Charge Temperature	0 to +60°C @60±25% Relative Humidity
Case	ABS, Metal Optional
Weight	Approx. 45kg
Dimension	640*260*220mm/ Customization

Features:

1. Under normal conditions, using lithium iron phosphate battery technology, with excellent safety, no explosion,no fire.

8000 cycles, 100% DOD.

2. Internal BMS with full protection, prevent overcharging, overdischarging, overcurrent and overheating.

3. Maintenance free.

4. Light weight: about 40%~50% of the weight of lead acid batteries.

5. Wide temperature range: -20 ℃ ~ 65 ℃ .

6. Support for series and parallel application extensions .

7. Quick charging,low self-discharge rate, ≤3%/month.















BMS Function introduction:



The BMS is designed for 16 series lithium battery



The BMS have all functions which are:



1. Overcharge detection function
2. Over discharge detection finction
3. Over current detection function
4. Short detection function
5. Temparature detection functions
6. Balance function
7. Communicate function
8. Alarm function
9. Total capacity function
10. Storage history function































































































































FAQs:

Q: Are you manufacturer?

A: We are manufacturer, and we sincerely welcome you to visit our factory!

Q. Can I print my LOGO on it?

A: YES, LOGO/sticker/OEM/ODM welcomed

Q: Do you accept OEM/ODM?

A: Yes,it is available.We have OEM group to design battery case.

Thanks to send us your requirements to custom the batteries.

Q: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.

Contact us for more informations!
