|Nominal Capacity:||105Ah||Cell Combine:||8S1P|
|Customized:||Yes||Case:||IP65 Plastic Box|
LiFePO4 Battery Pack 24V 100Ah Lithium Iron Phosphate Battery
* THESE ARE 8 CELL 24V BATTERY PACKS WITH NO BMS.
* Completely sealed
* Half the weight of an equivalent Ah deep cycle SLA battery.
* Smaller size than an equivalent SLA battery.
* 24V package, 25.6V nominal, 21.6V – 29.2V working range
* Recommend EV Power BMS balancers and/or monitors be installed.
* Packs may be dissassembled and/or connected in series fo higher voltage applications.
|Specifications||24v 100ah lifepo4 battery pack|
|Battery model||lifepo4 battery pack 24v 100ah|
|Cell specification||3.2V 105Ah cell|
|Type||24v 100ah lifepo4 battery|
|Discharge cut-off voltage||21.6V|
|Charge cut off voltage||29.2V|
|Rated discharge current||100A 50A 30A 10A available|
|Peak discharge current||150A 100A 50A ..|
|Max continuous charge current||0.5C|
|Peak charge current||1C|
|Charge Temperature Range||0-45C|
|Discharge Temperature Range||-20-60C|
|Charging cycles||More than 2500 times|
If you are able to build battery pack by yourself .TWe do not recommend operation in serial connection. For system with higher voltage 12V/24/36/48V and more, we recommend to use Single cells 50Ah 75Ah 90Ah 105Ah 200Ah 300Ah 400Ah + BMS123Smart
These batteries are suitable for all traction applications including electric vehicles. Fully complies also for stationary applications - such as energy storage.
Also possible to use for starting internal combustion engines. In the Principles do not require any special electronics for use LP 24V batteries for starting, but it is very important to keep min. and max. voltage, so we recommend using any voltage indication unit, which you will be informed about the current Voltage. This is important especially for frequent starting. We recomend use some simple car Voltmeter.
You can use a indication voltmeter PROM-VOLT
There is no Selfdischarging effect.
Can be recharged at any state of discharge - no memory effect
LiFePO4 is a very safe technology, not spontaneous combustion, does not react with moisture or with oxygen.
The rules for use and storage of batteries
Protect from improper handling.
Do not insert with opposite polarity, follow the signs. If the batteries are inserted in reverse, can cause a short-circuit or charging.
Prevent short-circuiting. If possitive (+) and negative (-) battery terminals are connected, short-circuiting happens.
Before installing, clean the terminals of battery and the terminals facilities.
The LiFePO4 should be always mounted with the terminals facing upwards.
Do not heat excessively. – batteries operate at temperatures according to the specifications.
Do not weld the cells.
Do not disassemble. When open may be contact with different parts of the battery harmful.
Do not distort. Batteries should not be compressed, punctured or damaged in any way.
Do not dispose of in fire.
Do not expose to water or excessive humidity.
Keep away from children. Beyond their reach, it is necessary first of all to keep away batteries which can be swallowed. In addition, children should not be allowed replacement of batteries without adult supervision.
Do not incase or modify. Any modifying of the battery may cause block safety ventilation mechanism. Any adjustments should consult the dealer.
Unused batteries should be stored charged and keep them away from metal subjects, which can make short-circuiting the battery. Alreary unpackage units should not be mixed and stored with unused batteries.
Avoid extreme humidity (over 95%) High temperature or humidity may worsening of battery characteristics and / or corrosion of the surface.
Do not storage / expose the battery to direct sunlight, in places where they may be exposed to rain, excessive heat such as radiators or heaters.
Batteries stored in well-ventilated and dry environment, ideally enclosed in a protective case.
During storage, keep the temperature within the range according to the specifications of a particular article.
Do not mix with other materials.
Do not stack cardboard box with batteries. When stacking may cause deformation of the battery in the lower layers and the subsequent flow of electrolyte.
For additional transportation / handling and packing materials, choose the method of packaging to prevent unintentional electrical contact and corrosion terminals, providing protection against environmental influences and mechanical damage.
Considerate handling of the boxes. Rough handling can cause a short circuit or damage.
Ensure proper circulation of stocks, follow FIFO system (First In, First Out).
Check the voltage of the cell every 2 month. Charge the cell if the voltage dropped to a minimum value of voltage
Battery operate under the supervision or constant monitoring protection and control systems. Protect against overcharge and deep-discharge.
