LiFePO4 Lithium Battery 48V 100AH 200AH OEM ODM Lithium Ion Battery 10KW Rechargeable Home Solar Energy Storage Battery
Contact Person : Hunan Chalong Fly Energy Technology Co., Ltd.
| Minimum Order Quantity : | 10-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLTF-0235 |
|
Detail Information |
|||
| Rated Capacity:: | 100Ah/200Ah/300Ah | Nominal Voltage: | 51.2V |
|---|---|---|---|
| Energy: | 10Wh | Weight: | 120KG |
| OEM/ODM: | Avaliable | Operation Temperature Range: | 0℃-45℃ |
| Application: | Home, Solar System, Industrial, Villa, Telecom | Usage: | UPS, Solar System, Camping Car, Emergency, Telecom |
| High Light: | Tesla Powerwall Lithium Ion Battery 200ah,10kwh ESS Lithium Ion Battery,200ah 48V Home Backup Battery Pack |
||
Product Description
If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.
Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| Model | CLTF-0235 | CLTF-0235 |
| Cell Type - Chemistry | Prismatic- LiFePO4 | Prismatic- LiFePO4 |
| Rated Capacity | 100Ah | 200Ah |
| Rated Voltage | 51.2V | 51.2V |
| Energy | 5KWh | 10KWh |
| Resistance | 30mΩ | 20mΩ |
| Self Discharge | <1.5% per month | <1.5% per month |
| Maximum Modules in Parallel | 4 | 4 |
| Dimensions (L x W x H) | 720*445*220mm | 820*720*220mm |
| Weight | 60Kg | 120Kg |
| Enclosure Protection | IP65 | IP65 |
| Discharge Cut-off Voltage | 48V | 48V |
| Max Continuous Discharging Current | 80A | 120A |
| Peak Discharge Current | 120A for 3 seconds | 150A for 3 seconds |
| Recommended Discharge Current | 50A | 100A |
| Charging Limited Voltage | 57.6V | 57.6V |
| Max Charging Current | 50A | 100A |
| Recommended Charge Current | 25A | 50A |
| Charge Temperature Range | 0~45℃ | |
| Discharge Temperature Range | -20~60℃ | |
| Recommended Operating Temperature | 15~35℃ | |
|
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH | |
|
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH | |
| Recommended Storage Temperature & Humidity Range | 15~35℃, 45~75%RH | |
Battery design:
Customer feedback:
Features:
1. Most safe LFP battery technology, no cobalt.
2. Long lifetimes - 6000cycles (80%DOD,25°C).
3. Easily expandable.
4. Self-engineered BMS with cell level monitor.
5. Short circuit/ Over current/Over voltage/Over temperature protection.
6. APP available on request to see the status of the battery.
7. Strong steel case with white color(optional).
8. Multiple communication access, Bluetooth, RS485, CANBUS.
9. IP65 waterproof.
10. OEM logo available.
To Pack Wall-Mounted Lithium Ion Battery well. Generally, as follow:
