LiFePO4 Lithium Battery 60V 72V Lithium Ion EV Battery Pack OEM ODM 40AH 80AH For Electric Wheelchair Lifepo4 Battery

Minimum Order Quantity :	10-1000 units	Price :	Negotiable
Packaging Details :	Wooden case and Carton case	Delivery Time :	7-15 working days
Payment Terms :	T/T	Supply Ability :	1000 units per month

Place of Origin:	Hunan,China	Brand Name:	CLTF
Model Number:	CLF-0023

Detail Information
Certification:	CE/ROHS/MSDS/UN38.3, CE/ROHS/MSDS/UN38.3	Nominal Capacity:	30AH/ 40AH/ 50AH/ 60AH/ 80AH
Nominal Voltage:	48V/60V/72V	The Charging Ratio:	2A-5A Included
Weight:	21.8KG	The Discharge Rate:	20A-120A
Application:	Power Tools, Home Appliances, BOATS, Golf Carts	Cycle Life:	6000 Cycle @ 100% DOD, 80% Capacity Remain
Fit For Motor:	250W-5000W	Type:	18650 Battery Pack
Chargeable:	Yes	OEM/ODM:	Yes
High Light:	48V EV Battery Pack , 50AH EV Battery Pack , Interface Lithium Iron Battery Pack

Product Description

CUSTOM 60V 72V 45AH 50AH 65AH Lifepo4 Lithium Electric Scooter Battery Pack

If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.

Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.

Function Parameter
Norminal Battery Energy	3900wh
Norminal Capacity	65Ah
Norminal Voltage	60V
Internal Resistance	≤22mΩ
Cycle Life	>6000
Months Self Discharge	<3%
Charge Data
DC Normal Charge Voltage	54.75±1Vdc
Charge Mode	0.2C to 54.75V, then 54.75V,charge current to 0.02C (CC/CV)
Recommended Charger Current	≤50A
Allowed Max. Charge Current	50Adc
Charge Cut-off Voltage	54.75±1Vdc
Discharge Data
Continuous Discharge Current	50A
Allowed Max. discharge current	100A (option:100Adc)
Rang of DC discharge voltage	37.5V-54.75Vdc
Working Condition
Charge Temperature	0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature	-20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature	0℃ to 40℃ (32℉ to 104℉) @60±25% Relative Humidity
Enclosure Protection Level	IP20
Mechanical Data
Cell & Method	48V100Ah, Prismatic
Shell material	Iron

Features of Electric Motorcycle Battery:
1. Lighter weight, smaller size.
2. High-temperature performance.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Excellent large current discharge performance especially in startup and climbing.
7. Large capability and long life for all high-power output applications.
8. Environmentally friendly non-toxic, non-contaminating, no rare metal.
9. Low self-discharge and good discharge performance at low temperatures.
