Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs

Minimum Order Quantity : 1 unit Price : Negotiable
Packaging Details : Wooden case and Carton case Delivery Time : 7-15 working days
Payment Terms : T/T Supply Ability : 1000 units per month
Place of Origin: Hunan,China Brand Name: CLTF
Certification: CE Model Number: CLF-0012

Detail Information

Nominal Capacity: 200Ah Nominal Voltage: 12.8V
Operation Temperature Range: 0℃-45℃ Cycle Life: 1500 Times
Size: 330mm*173mm*216mm Weight: 12.5KG
Custom: Accept Usage: Electric Vehicles, Electric Wheelchairs, Start-up Power Supplies, Energy Storage Lighting, Power
High Light:

Ternary 200Ah Lithium Battery

,

12.8V 200Ah Lithium Battery

,

3S Lithium Battery

Product Description

Electric Vehicles Wheelchairs EV Energy Storage Ternary Lithium 3S Lithium Battery Pack

Model CLF-0012
Rated Capacity 200Ah
Nominal Voltage 11.1V
Serialization 3S
Internal resistance ≤100mΩ
Discharge cutoff voltage 9V
Charging protection voltage 12.6V
Max. Charging voltage 12.75V
Maximum discharge current 80A
Maximum charge current 50A
Peak current 150±3A 2S

Rated discharge

Current

50A
Charging method CC/CV

Cycle

(+25℃ 0.2C 100%DOD)

1500 times
Operating Temperature Range Charging: 0~45℃
Discharge:-20~55
Storage temperature

-10~35℃

(60-80% SOC storage,

need to recharge every 2 months)

Dimension parameters
L*W*H 330mm*173mm*216mm
Weight 12.5KGS
Packaging and Delivery
Packaging details Standard carton with wooden package
Battery
Three yuan soft pack battery
Cycle Graph:


Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 0

Cell discharge performance:
Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 1





Model: 12V/200AH

Specification L x W x H: 330mm*173mm*216mm

Parameters: working temperature -20°C ~ 60°C, ternary lithium 3S, continuous working current 80A, 50A charging, instantaneous maximum current 150A (2S), M8 pure copper stud interface, charging upper limit 12.6V, discharge cut-off 9V, lead acid outer casing, weight of 12.5KG. (There are four colors and 50 different sizes for users to choose)

Applications: electric vehicles, electric wheelchairs, start-up power supplies, energy storage lighting, power



Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 2Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 3

Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 4

Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 5



Ternary 12.8V 3S 200Ah Lithium Battery Pack For Electric Vehicles Wheelchairs 6





FAQs:


Q: Are you manufacturer?

A: We are manufacturer, and we sincerely welcome you to visit our factory!


Q. Can I print my LOGO on it?

A: YES, LOGO/sticker/OEM/ODM welcomed


Q: Do you accept OEM/ODM?

A: Yes,it is available.We have OEM group to design battery case.

     Thanks to send us your requirements to custom the batteries.


Q: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
