25.6V 105Ah LiFePO4 Truck Starting Battery with 1000CCA for Parking Air Conditioner Power

Contact Now

25.6V 105Ah LiFePO4 Truck Starting Battery with 1000CCA for Parking Air Conditioner Power

Minimum Order Quantity :	2 Packs	Price :	Negotiable
Packaging Details :	Each battery is packed in a protective PE bag with foam cushioning and a strong export carton. Wooden cases or pallets are available for bulk orders.	Delivery Time :	25–35 Working Days
Supply Ability :	2,000 Pieces per Month

Place of Origin:	Hunan,China	Brand Name:	Chalongfly
Certification:	UN38.3, MSDS	Model Number:	CLF-TRK-DP-25V105Ah

Detail Information

Highlight:

25.6V 105Ah LiFePO4 truck battery

truck starting battery with 1000CCA

LiFePO4 battery for parking air conditioner

Product Description

Dual-Purpose Truck Starting & Parking AC Power

25.6V 105Ah LiFePO4 Truck Starting Battery

2.688kWh dual-purpose lithium battery with 1000CCA reference cranking performance for heavy-duty truck engine starting and parking air conditioner auxiliary power.

One Battery for Starting and Parking Air Conditioning

The Chalongfly 25.6V 105Ah LiFePO4 truck battery combines two important functions in one battery platform: high-current engine starting and deep-cycle auxiliary energy for parking air conditioners and sleeper-cab electrical loads.

The featured configuration provides 2.688kWh of nominal energy together with 1000CCA reference cranking performance for compatible heavy-duty truck applications.

Smart BMS, optional Bluetooth monitoring and optional low-temperature self-heating can be configured according to vehicle and fleet requirements.

Main Specifications

Model	CLF-TRK-DP-25V105Ah
System Voltage	24V Truck Electrical System
Nominal Voltage	25.6V
Rated Capacity	105Ah
Nominal Energy	2688Wh / 2.688kWh
Battery Chemistry	LiFePO4
Reference CCA	1000A
Reference Continuous Discharge	100A
Reference Peak Discharge	200A
Dimensions	350 × 340 × 237.4mm
Approximate Weight	30kg

1000CCA Heavy-Duty Engine Starting

Heavy-duty diesel engines require substantial current during starting. The reference 25.6V 105Ah configuration provides 1000CCA for compatible truck starting applications.

Vehicle Matching Required

Final compatibility depends on engine displacement, starter motor demand, battery temperature, cable resistance and vehicle electrical architecture.

2.688kWh for Parking Air Conditioning

25.6V × 105Ah = 2.688kWh

The battery stores auxiliary energy for compatible parking air conditioners, sleeper-cab equipment and onboard electrical loads while the truck engine is off.

Runtime Depends on Actual Load

Parking air conditioner runtime depends on average power consumption, compressor duty cycle, ambient temperature, cabin insulation and usable battery energy.

Smart BMS and Battery Monitoring

Overcharge protection
Over-discharge protection
Over-current protection
Short-circuit protection
Temperature protection
Cell balancing
Optional Bluetooth monitoring
Optional low-temperature self-heating

Truck Electrical System Compatibility

Replacing a conventional truck starter battery with LiFePO4 requires more than matching voltage and capacity.

Starting Current	Must Match Engine and Starter Motor
Alternator	Charging Voltage Must Be Confirmed
Battery Compartment	Dimensions and Mounting Must Be Verified
Terminals and Cables	Current Rating and Polarity Must Be Confirmed
Parking AC	Rated and Average Power Required for Runtime Calculation

Optional Bluetooth Monitoring

Bluetooth monitoring can be configured to provide convenient access to battery SOC, voltage, current, temperature and operating status through a compatible mobile APP.

Optional Self-Heating

A low-temperature self-heating configuration is available for truck applications requiring reliable charging in cold-weather operating environments.

Typical Applications

Heavy-Duty Truck Starting High-current LiFePO4 starting power for compatible diesel trucks	Parking Air Conditioner Auxiliary battery energy for sleeper-cab climate control while parked
Long-Haul Trucks Dual-purpose starting and auxiliary power for long-distance fleet operation	Lead-Acid Replacement Engineered lithium upgrade for compatible 24V truck electrical systems

OEM and ODM Customization

Battery capacity and cranking performance
Smart BMS configuration
Bluetooth APP monitoring
Optional self-heating
Steel enclosure dimensions
Terminal position and polarity
High-current power cable
Vehicle charging integration
Product label and model number
Logo and private-label packaging

Information Required for Battery Selection

Truck brand and model
Engine type and displacement
Original battery voltage and capacity
Original battery CCA
Battery compartment dimensions
Alternator charging voltage
Parking air conditioner rated and average power
Required parking runtime
Terminal and cable configuration
Estimated annual order quantity

Frequently Asked Questions

Is this a starter battery or a deep-cycle battery?

It is a dual-purpose battery designed for both high-current truck engine starting and repeated auxiliary-power use for parking air conditioning.

How much energy does it provide?

The 25.6V 105Ah configuration provides 2688Wh, or 2.688kWh, of nominal energy.

What is the cranking rating?

The current reference configuration lists 1000CCA. Final engine-starting compatibility should be confirmed from the truck starter requirement.

How long can it power a parking air conditioner?

Runtime depends on the air conditioner average power, compressor duty cycle, temperature and usable battery energy. Provide the air conditioner power data for an accurate calculation.

Can the existing alternator charge it?

Only after alternator voltage and charging strategy are confirmed to be compatible with the LiFePO4 battery and BMS.

Is Bluetooth available?

Yes. Bluetooth battery monitoring can be configured as an optional function according to the selected BMS.

What information is required before ordering?

Please provide the truck model, engine information, original battery specification, alternator voltage, battery compartment dimensions, parking AC power, required runtime and terminal configuration.

Configure a Dual-Purpose Truck Battery

Send Chalongfly your truck model, original battery data, required starting current, alternator charging voltage, parking air conditioner power and expected parking runtime. Our engineering team will evaluate the battery, BMS, enclosure, terminals, heating and monitoring configuration for your vehicle.
