36V & 48V 105Ah LiFePO4 Golf Cart Battery with Smart BMS for Fleet Vehicles

Contact Now

36V & 48V 105Ah LiFePO4 Golf Cart Battery with Smart BMS for Fleet Vehicles

Minimum Order Quantity :	2 Packs	Price :	Negotiable
Packaging Details :	Each battery is packed in a protective PE bag with foam cushioning and a strong export carton. Wooden cases or pallets are available for bulk orders.	Delivery Time :	25–35 Working Days
Supply Ability :	300 Packs per Month

Place of Origin:	Hunan,China	Brand Name:	Chalongfly
Certification:	UN38.3, MSDS	Model Number:	CLF-GC-105Ah-36V48V

Detail Information

Highlight:

36V 48V LiFePO4 golf cart battery

105Ah golf cart battery with BMS

lithium golf cart battery for fleet vehicles

Product Description

36V & 48V Golf Cart Fleet Power

36V 48V 105Ah LiFePO4 Golf Cart Battery

Smart lithium traction battery solutions for golf courses, resorts, sightseeing vehicles and commercial golf cart fleets.

Product Overview

The Chalongfly 105Ah LiFePO4 golf cart battery series is designed for 36V and 48V electric golf cart systems requiring reliable traction power, intelligent battery protection and long-term fleet operation.

The 36V system uses a 38.4V 105Ah battery providing 4032Wh of nominal energy, while the 48V system uses a 51.2V 105Ah battery providing 5376Wh.

Smart BMS protection, Bluetooth monitoring, matched chargers, high-current BMS options and vehicle-specific connectors can be configured according to the target golf cart.

36V and 48V 105Ah Configurations

Specification	36V System	48V System
Nominal Voltage	38.4V	51.2V
Rated Capacity	105Ah	105Ah
Nominal Energy	4032Wh	5376Wh
Maximum Charge Voltage	43.8V	58.4V
Reference Charge Current	50A	50A
Reference Continuous Discharge	150A	150A
Reference Peak Discharge	300A	300A
Dimensions	395 × 312 × 243mm	472 × 312 × 243mm
Approx. Weight	37kg	45kg

Choose the Correct Golf Cart Voltage

36V Golf Cart System

The 38.4V 105Ah configuration provides 4032Wh of nominal energy for compatible 36V golf carts.

48V Golf Cart System

The 51.2V 105Ah configuration provides 5376Wh of nominal energy for compatible 48V golf carts requiring greater available energy.

High-Current BMS for Traction Applications

The correct BMS current should be selected according to motor power, controller current, vehicle weight and terrain rather than using one fixed current rating for every golf cart.

Reference Continuous Current	150A
Reference Peak Current	300A
Higher-Current BMS	Available According to Vehicle Requirements
Selection Factors	Motor Power, Controller Current, Vehicle Load, Acceleration and Hill Grade

Smart Battery Monitoring

Smart BMS and monitoring functions help operators understand battery status and support efficient golf cart fleet management.

Integrated Smart BMS	Bluetooth Monitoring Available
SOC Display Optional	CAN / RS485 Optional
Self-Heating Optional	GPS Optional

Built for Golf Cart Fleets

Golf Courses Reliable traction power for daily course fleet operation	Hotels and Resorts Battery systems for shuttle carts and resort mobility vehicles
Sightseeing Fleets Traction solutions for tourism and recreational transportation	Utility Carts Customized battery systems for compatible commercial utility vehicles

Complete Golf Cart Battery System

Matched LiFePO4 charger
SOC display
Bluetooth battery monitoring
DC/DC voltage reducer
Battery mounting bracket
Main power connector
Customized battery cable harness
Charging receptacle and related accessories

OEM and ODM Customization

BMS continuous and peak current
Battery enclosure dimensions
Main connector and cable harness
CAN or RS485 communication
Matched charger
Display and Bluetooth monitoring
Mounting bracket and accessories
Logo, label and packaging customization

Information Required for Battery Selection

Golf cart brand and model
Original system voltage
Motor rated and peak power
Controller maximum current
Battery compartment dimensions
Main power connector
Required driving range
Existing charger information

Frequently Asked Questions

What is the nominal voltage of the 36V version?

The 36V golf cart system uses a 38.4V nominal LiFePO4 battery configuration.

What is the nominal voltage of the 48V version?

The 48V golf cart system uses a 51.2V nominal LiFePO4 battery configuration.

How much energy does each battery provide?

The 38.4V 105Ah version provides 4032Wh, while the 51.2V 105Ah version provides 5376Wh of nominal energy.

Is a higher-current BMS available?

Yes. Higher-current configurations can be evaluated according to motor power, controller current, vehicle load and hill-climbing requirements.

Can a matched charger be supplied?

Yes. A matched LiFePO4 charger can be supplied according to the selected 36V or 48V battery configuration.

What information is required before ordering?

Please provide the golf cart model, system voltage, motor power, controller current, battery compartment dimensions, connector type, charger information and required driving range.

Select the Right 105Ah Golf Cart Battery

Send Chalongfly your golf cart voltage, motor power, controller current, battery compartment dimensions and required driving range. Our team will evaluate whether the 36V or 48V 105Ah LiFePO4 configuration is the better match for your vehicle.
