LiFePO4 Lithium Battery 48V 72V 96V 40AH 200AH 300AH 400AH Rechargeable EV Golf Cart OEM ODM Lithium Ion Battery
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 1-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLF |
|---|---|---|---|
| Certification: | CE/ROHS/MSDS/UN38.3 | Model Number: | CLFC-0121 |
|
Detail Information |
|||
| Features: | Cost Effective, Fast Delivery, Stable Structure | Battery Type: | LiFePO4 Battery, Li-ion Battery, Lithium Battery, NMC |
|---|---|---|---|
| Voltage: | 12V/24V/48V/96V/144V | Capacity: | 40AH, 80AH, 120AH, 200AH, 300AH, 400AH, 500AH |
| Application: | Electric Vehicle, Electric Boat, Electric Yacht, Marine | Dimension: | Customized |
| OEM/ODM: | Yes | Keywords: | Lithium Battery, LiFePO4 Battery Pack, NMC Battery, Marine Battery |
| Battery Case: | Metal | Transport Package: | Foam & Plywood Case |
| Waterproof Standard: | IP67 | ||
| Highlight: | 12V LiFePO4 Lithium Battery,Customized LiFePO4 Lithium Battery,120AH 144AH LiFePO4 Lithium Battery |
||
Product Description
If you don't see any products that match your requirements, please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 50Ah |
| Rated Voltage | 76.8V |
| Energy | 3.84kWh |
| Resistance | 30mΩ |
| Self Discharge | <4% per month |
| Modules in Series | 4S1P to 307.2V 50Ah battery pack |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 500*370*160 |
| Weight | 32Kg/module |
| Enclosure Protection | IP67 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 60V |
| Max Continuous Discharging Current | 50A |
| Peak Discharge Current | 100A for 30 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 87.6V |
| Max Charging Current | 50A |
| Recommended Charge Current | 25A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45ºC |
| Discharge Temperature Range | -20~60ºC |
| Recommended Operating Temperature | 15~35ºC |
| Storage Temperature & Humidity Range (Less than 1 month) |
-20~35ºC, 45~75%RH |
| Storage Temperature & Humidity Range (Less than 3 months) |
-10~35ºC, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35ºC, 45~75%RH |
| OEM | |
| Available on request | yes |
Features of Electric Golf Cart Battery:
1. Lighter weight, smaller size.
2. High-temperature performance.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Excellent large current discharge performance especially in startup and climbing.
7. Large capability and long life for all high-power output applications.
8. Environmentally friendly non-toxic, non-contaminating, no rare metal.
9. Low self-discharge and good discharge performance at low temperatures.
