CLF OEM ODM Golf Cart Forklift Motorcycle Lifepo4 Lithium Battery 36V 48V 72V BMS CAN RS485 6000cycles Lead Acid
Contact Person : CLF
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 10 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLTF-0224 |
|
Detail Information |
|||
| Rated Capacity:: | 12Ah | Nominal Voltage: | 12.8V |
|---|---|---|---|
| Energy: | 153.6Wh | Size: | 151*98*95*101mm |
| High Light: | 12V 12Ah AGM Solar Battery,Phosphate Deep Cycle AGM Solar Battery,CE Certificate AGM Solar Battery |
||
Product Description
Specifications:
| Nominal Voltage | 12.8V |
| Nominal Capacity | 12Ah |
| Energy | 153.6Wh |
| Internal Resistance | 70≤mΩ |
| Cycle Life | >2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity |
| Months Self Discharge | ≤3.5% per month at 25℃ |
| Charge Voltage | 14.6±0.2V |
| Charge Mode(CC/CV) |
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A. |
| Charger Current | 2.4A |
| Max.Charge Current | 6A |
| Discharge Current | 2.4A |
| Max. Continuous Current | 12A |
| Max.Pulse Current | 30A(<3S) |
| Disxcharge Cut-off Voltage | 10.0V |
| Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Disxcharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
| Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Water Dust Resistance | IP55 |
| Cell & Method | IFR32700 N60,4S2P |
| Plastic Case | ABS |
| Dimension(L*W*H*TH) | 151*98*95*101mm |
| Weight | 1.55kg |
| Terminal | F2 |
Features:
1. Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions.
Design picture:
Applications:
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Contact us for more information!
