LiFePO4 Lithium Battery 48V 72V 96V 40AH 200AH 300AH 400AH Rechargeable EV Golf Cart OEM ODM Lithium Ion Battery
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
Minimum Order Quantity : | 2 unit | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
Payment Terms : | T/T | Supply Ability : | 1000 units per month |
Place of Origin: | Hunan,China | Brand Name: | Chalong Fly |
---|---|---|---|
Certification: | CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc | Model Number: | CLFLE166 |
Detail Information |
|||
Capacity: | 60Ah | Voltage: | 48V |
---|---|---|---|
Serialization: | 14S | Dimensions: | 280mmX242mmx166mm |
Weight: | 23.5KG | Usage: | EV, RV, UPS, Electric Car, E-bike, Telecom |
Battery: | Ternary Soft Pack Power Battery | Configuration: | Chrome Handle, Insurance, GPS Optional |
Maximum Discharge Current: | 100A | Maximum Charge Current: | 30A |
Highlight: | Road Sweeper EV Battery Pack,Customized EV Battery Pack,48v 60ah Lithium Ion Battery |
Product Description
OEM ODM LiFePO4 lithium battery pack NMC NCM EV Battery Pack for Road Sweeper Outdoor Lithium Ion Battery Customized
If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.
Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
Model | CLF-0030 | |
Rated Capacity | 60Ah | |
Nominal Voltage | 48V | |
Serialization | 14S | |
Internal resistance | ≤100mΩ | |
Discharge cutoff voltage | 39.2V | |
Charging protection voltage | 58.8V | |
Max. Charging voltage | 59.5V | |
Maximum discharge current | 100A | |
Maximum charge current | 30A | |
Peak current | 150±5 2S | |
Rated discharge Current |
30A | |
Charging method | CC/CV | |
Cycle (+25℃ 0.2C 100%DOD) |
1200 times | |
Operating Temperature Range | Charging: 0~45℃ | |
Discharge:-20~55℃ | ||
Storage temperature |
-10~35℃ (60-80% SOC storage, need to recharge every 2 months) |
|
Dimension parameters | ||
L*W*H | 280mmX242mmx166mm | |
Weight | 23.5KG | |
Packaging and Delivery | ||
Packaging details | Standard carton with wooden package | |
Battery: | ||
Three yuan soft pack power battery | ||
Configuration | ||
handle, insurance, GPS optional | ||
Different rate discharge curves: | ||
Model: 48V60Ah
Dimension: 280mmX242mmx166mm
Features: ternary soft pack lithium battery, 14S;
charge cut-off voltage: 58.8V;
discharge cut-off voltage:39.2V;
rated current:50A;
protection current:100A;
weight:23.5KG
Application: electric car, tricycle, Four-wheeled vehicle, electric motorcycle
FAQ:
Q1. Are you a factory?
A: Yes, we are a professional lithium battery manufacturer in China, and factory tour is acceptable.
Q2. Do you accept OEM/ODM?
A: Yes, OEM, ODM, LOGO, and STICKER is acceptable, our professional team is on hand to offer you any solutions.
Q3. Can I have a sample order first?
A: Yes, sample order is acceptable.
Q4. How will my order be shipped?
A: Chalong Fly offers a variety of shipping methods, such as DHL, UPS, FedEx, TNT, Airline and sea shipping.
Q5: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Q6. Can we sign a NDA in order for a long-term cooperation?
A: Yes, the client’s requirements is respected.
O7: Is there any warranty or After-Sale Service?
A: We will check each battery before shipment, and 100% high quality guaranteed. The warranty is about 1~20 years depends on different models.
Q8. Why do you choose Chalong Fly?
A: Chalong Fly R&D center has more than 60 R&D engineers, 12 of whom have more than 10 years of experience related to power development. We have a deep understanding of power electronics technology, and a full understanding of the needs of the application industry, and have developed many public technology solutions.
