LiFePO4 Lithium Battery 48V 72V 96V 40AH 200AH 300AH 400AH Rechargeable EV Golf Cart OEM ODM Lithium Ion Battery
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsAPP : +8618975107916
| Minimum Order Quantity : | 10 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLF |
|---|---|---|---|
| Certification: | ISO9001, UN38.3, CE, CB,MSDS | Model Number: | CLF-R0207 |
|
Detail Information |
|||
| Nominal Voltage: | 72V | Rated Capacity:: | 20Ah |
|---|---|---|---|
| Dimensions: | 75*210*375mm | Energy: | 1440Wh |
| Self Discharge: | <1.5% Per Month | Weight: | 11KG |
| Charge Current: | 5A | Discharge Current: | 20A |
| OEM/ODM: | Accepted | Application: | E-motorcycle, Escooter, Ebike, E-rickraw, E-motorcycles Etc |
| Highlight: | Electric Motorcycle NCM Lithium Battery Cell,20Ah NCM Lithium Battery Cell |
||
Product Description
Rechargeable Lithium Ion Battery Pack 72V 20Ah NCM Battery For Eletric Motorcycle
Specifications:
| MODEL | CLF-R0207 |
| Cell Type - Chemistry | NCM |
| Rated Capacity | 20Ah |
| Rated Voltage | 72V |
| Energy | 1440Wh |
| Self Discharge | <1.5% per month |
| Dimensions | 75*210*375mm |
| Weight | 11kg |
| Discharge Cut-off Voltage | 60V |
| Max Continuous Discharging Current | 20A |
| Peak Discharge Current | 40A for 3 seconds |
| Recommended Discharge Current | <20A |
| Charging Limited Voltage | 84V |
| Max Charging Current | 5A |
| Recommended Charge Current | <5A |
| Charge Temperature Range | 0~45℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
|
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH |
|
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35℃, 45~75%RH |
| Life cycle |
>3500cycles |
Features:
1. NCM battery technology, 72V 20AH, 20S2P.
2. 3KW continue discharge power.
3. Smart BMS integrated in the battery pack.
4. Short circuit/ Over current/ Over voltage/ Over temperature protection.
5. Strong steel case.
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Contact us for more information!
