Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P

China Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P supplier
Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P supplier Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P supplier Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P supplier Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P supplier

Large Image :  Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P

Product Details:

Place of Origin: Shenzhen, China
Brand Name: HKANON
Certification: CE, UL, RoHS, MSDS, UN38.3
Model Number: HN-LFP

Payment & Shipping Terms:

Minimum Order Quantity: 1Pc
Packaging Details: 1PC/1 Wooden Box
Delivery Time: 10 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5,000Pcs/Month
Contact Now
Detailed Product Description
Product Name: Personal Transport Utility Passenger Lithium Golf Cart Battery 48V 100Ah 16S1P Cell Inside: 16S1P-3.2V 100Ah
Chemistry: LiFePO4 Application: RV, Motorhome, ESS, Solar Storage System, Energy Storage System
Ingress Protection: IP65 BMS: Included

Personal Transport Utility Passenger Lithium Golf Cart Battery 48V 100Ah 16S1P



Safety performance

  • Resistance to heavy loads. The battery pack shall be tested according to the regulations and shall not ignite or explode.
  • Resistance to thermal shock. The battery pack shall be tested according to the regulations and shall not ignite or explode.
  • Anti-overcharge. The battery module shall be tested according to the regulations and shall not ignite or explode.
  • Resistance to overdischarge. The battery module shall be tested according to the regulations and shall not ignite or explode.
  • Resistance to short circuit. The battery module shall be tested according to the regulations and shall not ignite or explode.
  • High temperature storage. The battery shall be tested according to the regulations and shall not leak, smoke, catch fire or explode.
  • Anti-heating. The battery module is tested according to the regulations. No part of the explosion battery penetrates the screen, and some or all of the batteries protrude from the screen.
  • Anti-puncture. The battery pack shall be tested according to the regulations and shall not ignite or explode.
  • Anti-extrusion. The battery module shall be tested according to the regulations and shall not ignite or explode.
  • Resistance to low pressure. The battery pack shall be tested in accordance with regulations and shall not leak, smoke, catch fire or explode.
  • Constant damp heat. After the battery pack is tested according to the regulations, its appearance shall be free from obvious deformation, rust, smoke or explosion, and its capacity shall not be less than 90% of the rated value.
  • Anti-vibration. The battery pack shall be tested according to the regulations, and its appearance shall be free from obvious damage, liquid leakage, smoke or explosion, and it can work normally.
  • Anti-collision. The battery pack shall be tested according to the regulations, and its appearance shall be free from obvious damage, liquid leakage, smoke or explosion, and it can work normally.
  • Temperature cycling. The battery pack shall be tested in accordance with the provisions of 6.6.15, which shall not leak, smoke, ignite or explode; the appearance of the battery pack shall be free of cracks, no loss of quality, and the capacity shall not be lower than 70% of the initial state.
  • Flame retardant properties. For battery packs with plastic casing and protective cover, the test shall be carried out in accordance with the provisions of 6.6.16. The outer casing shall comply with the provisions of Article 8.3.2 of the GB/T2408-2008, FH-1 (horizontal level) and 9.3.2 of FV-0 (vertical). Level) requirements.
  • Insulation resistance. For a battery pack with a metal case, the insulation resistance of the battery pack's metal and cathode housings is not less than 2 MW.



SPECIFICATIONS



MAIN KIT INCLUDES
1 x 48V100Ah LiFePO4 Battery
1 x 164S-50A PCM
1 x Plastic/Iron Battery Case
Normal Voltage 51.2V
Normal Capacity 100Ah
Battery Energy 5120Wh
Inner Resistance < 60mΩ
Battery Cycle Life 2500 Times @100%DOD
3500 Times @80%DOD
Cell Configuration 16S1P-3.2V 100Ah
Reference Battery Size (342±1)*(173±1)*(212±1) mm
Reference Battery Weight 38kg
Charge Voltage 58.4V
Charge Mode CC/CV
Normal Charge Current <=20A
Normal Discharge Current 50A
Max. Continuous Output Current 50A
Max. Continuous Output Power 2400W
Passive Protection Function Over charge protection; Over discharge protection; Over
current protection, etc
Operation Temperature Range Charge: 0'C---45'C
Discharge : -20'C---60'C
Battery Storage Temperature -20'C---25'C
Individual Cell Approval CE, UL, RoHS, MSDS, UN38.3







INTERIOR AND EXTERIOR GALLERY

Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P

Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P

Anti Overcharge 48 Volt Golf Cart Batteries , Golf Cart Batteries For RV 16S1P
