Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density

Good quality Lifepo4 Battery Pack for sales
Good quality Lifepo4 Battery Pack for sales
The shipment day is a litter bit late.but it is ok.all good were perfect.hope next cooperation.ths very much.

—— Greg Henk

We have received the battery packs and performing tests have passed . We are impressed by the assembly. it is almost the best one . thank you

—— Alexander Kozhushko

I'm Online Chat Now

Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density

China Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density supplier
Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density supplier Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density supplier Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density supplier Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density supplier

Large Image :  Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density

Product Details:

Place of Origin: CN
Brand Name: HKANON
Certification: CE MSDS UN38.3
Model Number: 24V 20Ah

Payment & Shipping Terms:

Minimum Order Quantity: 10
Packaging Details: 2PCS/Carton
Delivery Time: 5000PCS/Month
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2PCS/Carton
Contact Now
Detailed Product Description
Features: Rechargeable Lifepo4 Battery Model: 24v 20ah Lifepo4 Battery Pack
Work: Electric Bike Lifepo4 Battery Pack Material: Lifepo4 Battery 24v 20ah
Battery Pack Dimensions: Can Be Customized BMS: 30A

Rechargeable LiFePO4 Battery 24V 20Ah Electric Bike LiFePO4 Battery Pack





Model lifepo4 battery 24v 20ah
Nominal Voltage and Rated Capacity 24Volt 20Ah / Watt Hours: 500Wh
Configuration 8 Series 6 Paralles 8S6P-48PCS cells
Cells Brand 26650 3.2V 3300mAh Cells
BMS 30 Amp max continuous and 50A plusmn peak current(3-5 seconds)
Fit for Motor 24V 18W 20W 50W 60W 100W 200W 250W 300W 350W
Charge Current 2-5 A
Charge Cut-off Voltage 29.2V
Discharge Cut-off Voltage 21.6V
Packing List included: 1 x Lithium Battery Built-in cells and BMS
with 30CM discharge naked cable, or soldered default discharge connector
1 x29.4V 3A Charger With AC plug
Size Can be customized
Case Plastic Box or Iron Box or PVC+PET can be choosed



Charger plugs and Discharge connectors optional:

1. Charger Plug: US EU UK AU plugs optional, will provide according to delivery country if without requested.

2. Discharge Connector: There are 8 kinds optional as below picture, will provide naked cable or soldered with default connector if without requested.


Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density
Rechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy DensityRechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy DensityRechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy DensityRechargeable Electric Bicycle Lithium Battery 24Volt 20Ah High Energy Density
Lithium battery features

Longer battery life, the life expectancy is two times that of lead-acid batteries.
Rechargeable and no memory effect.
The weight is more lighter.
Smaller dimensions and can be customized.
Safer and more environmentally friendly, No heavy metals and hazardous substances.
BMS built-in IC chip will prevent battery pack over charge, over discharge, over-current,
over-heat, short circuit .

Warnings

Do not immerse the battery in water or seawater, keep the battery stands by in a cool dry surrounding.
Does not use or leave the battery near a heat source as fire or heater.
Use the battery charger specifically for that purpose when recharging.
Do not reverse the position and negative terminals.
Do not connect the battery electrodes to an electrical outlet.
Do not discard the battery in fire or a heater.
Do not short-circuit the battery by directly connecting the positive and negative terminals with metal objects.
Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
Do not strike, trample or throw the battery.
Do not directly solder the battery and pierce the battery with a nail or other sharp objects.

Shipping Ways

About Shipping:

Battery is a special product, all batteries need several cycle test before delivery, so production and
test time need about 3-7 days after confirm order;

For EU Countries customer:
Shipping by UPS/DPD, tracking number can be trackable online after arriving Europe.
Shipping time is usually 7-12 working days( not including Sat Sun) after delivery.

For USA Customers:
Shipping by Fedex/UPS, Shipping time is usually 6-12 working days after delivery.

Special Line:
1)Shipping by Special Line to Australia, Malaysia, Thailand, Taiwan, Shpping time is usually 4-12 working days.
2)Shipping by CDEK to Russia, tracking online update after arriving Moscow. Shipping time is usually 18-25 working days.
