High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell

China High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell supplier
High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell supplier High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell supplier High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell supplier High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell supplier

Large Image :  High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell

Product Details:

Place of Origin: USA
Brand Name: HKANON
Certification: UN38.3 IEC
Model Number: ANR26650M1B

Payment & Shipping Terms:

Minimum Order Quantity: 500PCS
Price: USD5.6-USD5.9/PC for 500PCS
Packaging Details: 100PCS/Inner Box
Delivery Time: 5-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000PCS/Month
Contact Now
Detailed Product Description
Name: A123 26650 Battery Material: LiFePO4
Weight: 76 Grams Type: ANR26650M1B
Rate: 50A Rate Storage: 8.25Wh

Rechargeable High Drain the best 20C ANR26650M1B 3.2V 2500 mAh A123 26650 Battery



Specifications
Model ANR26650 M1B
Nominal Voltage 3.25V +/-0.05V Nominal,3.2V Average
Nominal Capacity 2500 mAh(at 0.2C rate,3.65+/-0.05V cut-off)
Energy Density 108.10wh/kg
Charging current

standard charging :2.5A,1.0C rate

Maximum charging :10.0A ,4.0C rate

Discharging current

Max continuous discharge : 50A,20C rate

Max impulse discharge(< 10 sec): 120A, 48.0C rate

Temperature Range Charge and Discharge: -30°C to 55°C
Storage: -40 oC to 60 oC
Cycle Performance >1000 (100% of initial capacity at 20A discharge)
Dimensions(DxH) 26mm(1.0") x 65.15 mm(2.6")
Weight 2.9Oz (76 grams)
Tab Option The tab (part# TB-DHZ) can support surge discharge at 100A





Pictures

High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery CellHigh Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery CellHigh Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery CellHigh Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell

High Drain LiFePO4 20C 3.2V 2500mAh Batteri a123 anr26650m1a Battery Cell
