High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

Good quality Lifepo4 Battery Pack for sales
Good quality Lifepo4 Battery Pack for sales
The shipment day is a litter bit late.but it is ok.all good were perfect.hope next cooperation.ths very much.

—— Greg Henk

We have received the battery packs and performing tests have passed . We are impressed by the assembly. it is almost the best one . thank you

—— Alexander Kozhushko

I'm Online Chat Now

High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

China High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh supplier
High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh supplier High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh supplier High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh supplier High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh supplier

Large Image :  High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

Product Details:

Place of Origin: Shenzhen, China
Brand Name: HKANON
Certification: CE, UL, RoHS, MSDS, UN38.3
Model Number: HN-12V 20000mAHA

Payment & Shipping Terms:

Minimum Order Quantity: 1Pc
Packaging Details: 1PC/1 Carton
Delivery Time: 10 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5,000Pcs/Month
Contact Now
Detailed Product Description
Product Name: 12V 5000mAh 10000mAh 12000mAh 13000mAh 20000mAh 30000mAh 50000mAh Rechargeable Lithium Ion Battery Pack Cell Inside: 4S6P-3.2V 3300mAh IFR26650
Chemistry: LiFePO4 Application: Solar/ Wind Energy Storage, Backup Power For Small UPS, Etc
Ingress Protection: IP65 BMS: Included

12V 5000mAh 10000mAh 12000mAh 13000mAh 20000mAh 30000mAh 50000mAh Rechargeable Lithium ion Battery Pack



SPECIFICATION



Battery Type LiFePO4
Nominal Voltage 12.8V
Nominal Capacity 20Ah
Internal Resistance ≤20mΩ
Series & Parallel Application up to 4 series 7 parallel connected application
Limited Charge Voltage 14.6±0.2V
Floating Charge Voltage 13.8±0.2V
Charge Method CC/CV
Discharge Cut-off Voltage 10.8V
Max. Charge Current 5A
Max. Continuous Discharge Current (<30min) 30A
Pulse Discharge Current (<3s) 60A
Cycle Life > 2000 cycles
Dimension Length 181mm
Width 166mm
Height 76mm
Weight 3Kg
Operation Temperature Range Charge: 0~45℃;
Discharge: -20~60℃
Recommended operating temperature: 15℃~35℃
Self-Discharge Rate Residual capacity: ≤5%/month;





INTERIOR AND EXTERIOR GALLERY

High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh

OTHER RELATED PRODUCTS



Rechargeable LiFePO4 Battery pack for Solar Street Light

Voltage

(V)

Capacity

(Ah)

Stored energy

(Wh)

Dimension
(mm)
Battery cells Built in PCM
(Yes/No)
12.8 6.0 76.8 110*150*30 IFR26650 Yes
12.8 9.0 115.2 160*150*30 IFR26650 Yes
12.8 12.0 153.6 210*150*30 IFR26650 Yes
12.8 15.0 192 132*275*30 IFR26650 Yes
12.8 18.0 230.4 160*275*30 IFR26650 Yes
12.8 20.0 256 190*275*30 IFR26650 Yes
12.8 24.0 307.2 210*275*30 IFR26650 Yes
12.8 27.0 345.6 250*275*30 IFR26650 Yes
12.8 30.0 384 270*275*30 IFR26650 Yes
12.8 33.0 422.4 295*275*30 IFR26650 Yes
12.8 40.0 512 350*275*30 IFR26650 Yes
12.8 50.0 640 460*275*30 IFR26650 Yes
12.8 60.0 768 270*275*60 IFR26650 Yes
12.8 70.0 896 295*275*60 IFR26650 Yes
12.8 80.0 1024 350*275*60 IFR26650 Yes

Note: Our 3.2V 10Ah,12Ah, 20Ah battery cells can be assembled as hight power LiFePO4 modules.

It can be also used individully and can be connected in serial or parallet to achieve ideal voltage

and capacity





CERTIFICATE



Lithium Battery from HKANON have passed CE, UL, RoHS, MSDS, UN38.3, our battery including LiFePO4 motorcycle start battery, ebike battery, portable power station and solar light battery.



Also, each type has its product process, we have build a set of Quality Control System to manage the batteries production.

High Capacity 12V Rechargeable Battery Pack Anti Explosion 5000mAh 10000mAh



Secondly, we provide professional products catalog for you to browse quickly, each lithium-ion battery has analysis in detail. Contact us to get the product catolog and also the free sample of motorcycle battery on condition that you would like to pay the delivery fee.



Last but not least, user manual is important for you to read, it is a detailed description of the batteries’ features, performance and user interface, allowing users to understand how to use it. All in all, we are manufacturer who want to provide you the best batteries and service.
