80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

China 80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge supplier
80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge supplier 80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge supplier 80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge supplier 80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge supplier

Large Image :  80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

Product Details:

Place of Origin: CN
Brand Name: HKANON
Certification: CE RoHS MSDS UN38.3
Model Number: lifepo4 cell 80ah 90ah

Payment & Shipping Terms:

Minimum Order Quantity: 12PCS
Packaging Details: 12PCS/Carton
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10K/Month
Contact Now
Detailed Product Description
Name: 3.2v 80ah 90ah Lifepo4 Batteri Cell Nominal Voltage: 3.2v
Nominal Capacity: 90ah Cell Rate: 3C-270A
Weight: 1.95kgs Size: 201*131*37.2mm

Prismatic LFP Li Ion Battery 3.2V 80Ah 90Ah LiFePO4 Batteri Cell



Specifications
Nominal voltage 3.2V
Nominal Capacity 90Ah
Stanadard Charge Current 18A (0.2C)
Max Charge Current 45A(0.5C)
Max continuous Discharge Current 3C-270A
Charge Cut-off Voltage 3.65V
Discharge Cut-off Voltage 2.5V
Weight 1.95kgs
Dimensions 201*131*37.2mm
Operating Temperature

Charging: 0°C ~ 45°C,

Discharging: -20°C ~ 60°C

(The cell surface temperature cannot exceed 70°C)

Cycle Life at 0.2C Discharge, 100% DOD ≥2000 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard)
Accessories BMS ,charger ,bolts ,connectors



80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

80Ah Lifepo4 Prismatic Battery , LFP Battery Charger Low Self Discharge

Other products



Nominal Capacity Nominal Voltage Dimension (H*W*T) Weight Max Continuous Discharge Current
50Ah 3.2V 186*136*31(+/-1) mm 1.41+/-0.1kg 3C(150A)
100Ah 3.2V 221*142*61 (+/-1) mm 3.15+/-0.1kg 3C (300A)
200Ah 3.2V 280*180*69 (+/-1) mm 5.8+/-0.2kg 3C(600A)
300Ah 3.2V 308*360*53 (+/-1) mm 9.5+/-0.3kg 1C(300A)
400Ah 3.2V 285*400*71(+/-1)mm 14.3+/-0.3kg 1C(400A)
Cycle Life: > 2000 times @ 80% DOD, retention capacity ≥ 80%
