|Material:||NMC 18650||Name:||18650 Battery 3600mAh|
lithium ion pouch cell,
lfp battery charger
High Capacity Rechargeable Li-Ion Battery 3.7V 18650 3800mah 3600mah 6000mAh
|Product||18650 Battery 3600mAh|
|Nominal Voltage||Average 3.6V-3.7 V|
|Max Charge Full Voltage||4.2V|
Standard charging current 720mAh
Fast charging current 1800mAh
|Discharge Current||10.8A(3C Max)Continuous at 25°C|
|Operation Temperature||Charging: 0 - 45 °c
Discharging: - 20 - 60 °c
|Cycle Performance||800-1000 (80% of initial capacity at 0.2C rate, IEC Standard)|
|Dimensions(DxH) (max with tab)||18*65mm|
|Li-Ion Batteries may explode if charged or discharged improperly.
You must possess knowledge of electronic and understand how to handle Li-ion battery.
You should always use a protection circuit board (PCB) to keep battery from over charge and over discharge
Never solder directly onto the Li-ion battery as overheat might damage the battery. If you are making a pack or need to solder batteries together, you need to get battery with tabs on it. You will solder to tabs instead directly onto the battery.
